GAMDIAS BOREAS P1-720 DUAL TOWER CPU AIR COOLER BLACK
BOREAS-P1-720
GAMDIAS BOREAS P1-720 DUAL TOWER CPU AIR COOLER BLACK
Premium All-Black Coating
Aluminum Brushed Top Cover
Optimized Convex Copper Base
7 High-performance Copper Heat Pipes
Asymmetrical Heat Pipes
Dense 140 * 50mm Dual Aluminum Heatsink
2 Hydraulic Bearing PWM Fans
135mm Middle Fan & 120mm Front Fan
157.5mm Clearance & Height Compatibility
Support LGA 1700 / AM5
AIR COOLER - FAN
- Fan Dimensions 120 x 120 x 25 mm / 135 x 148 x 25 mm
- Fin Material Aluminum
- Fan Speed 600-1750 / 800-2000 RPM ±10%
- Air Flow 68.7 / 84.2 CFM
- Air Pressure 1.65 / 1.91 mmH2O
- Noise Level 10-31 dBA
- Bearing Hydraulic
AIR COOLER
- Heatpipe Material Copper
- Product Dimensions 148 x 162 x 157.5 mm
- Connector 4 Pin PWM
- Rated Voltage 12 V (Fan)
- Compatibility LGA2066 / 2011-v3 / 2011 / 1700 / 1151 / 1150 / 1155 / 1156 / 1200 / AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1
Gamdias CHIONE M4-360 CPU Liquid Cooler, 3X 120mm ARGB PWM Fans, RGB Sync with motherboards, Rotatable 2.1″ LCD Displays – BLACK
Gamdias CHIONE M4-360 CPU Liquid Cooler - BLACK
EXPERT FEATURES
- Rotatable 2.1" LCD Displays Real-time System Information
- New Cooling Route System for Better Performance
- Patented in-line PWM Pump up to 5400 RPM
- 25%-40% Increase in Radiator Fin Thickness
- Optimized Copper Base for Better CPU Contact
- CHIONE CAST LITE Software
- ARGB Motherboard Sync
- Hydraulic bearing PWM fans
- 450mm Durable Teflon Tube
- Aesthetic Nylon-braided Tube Sleeve
- Universal Mounting Kits
- Support LGA 1700 / AM5
EXPERT SPECIFICATIONS :
Model
- CHIONE M4-360
Package Contents
- Cooler ;1
- Fan ;3
- Thermal Grease ; 1
- Mounting Kit ; Yes
- GAMDIAS AEOLUS BOX Adapter Cable ; 1
LIQUID COOLER - FAN
- Dimensions ; 120 x 120 x 25 mm
- Speed ; 800 - 2000 RPM±10%
- Noise Level ; 11 - 29 dBA
- Air Flow ;69.01 CFM
- Air Pressure ;2.37 mmH2O
- Bearing ; Hydraulic
- Rated Voltage ; 12 V (Fan) / 5V(LED)
- Connector ; PWM & 5V sync
- Support PWM Control ; Yes
LIQUID COOLER
- Radiator Dimensions395 x 119 x 32 mm
- Tube Material ; Teflon
- Base Plate Material ; Copper
- Radiator Material ; Aluminum
- Sleeved Tube ; Yes
- Pump Rated Voltage12 V (Pump) / 5V(LED)
- Pump Connector4 Pin
- Compatibility ; LGA2066 / 2011-v3 / 2011 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1
- Support Motherboard RGB Sync Connectors ; 5V 3-pin addressable (digital) RGB header Only
FROM THE MANUFACTURER :
ELITE COOLING POWER
The CHIONE M4-360 liquid cooler delivers powerful cooling for your CPU through its patented in-line PWM pump, a 32mm thick radiator, and three 120mm ARGB fans to reach new levels of coolness. It also features a 2.1" LCD screen on the water block that displays CPU temperature, fan speed, and pump speed stats in real-time.REAL-TIME SYSTEM INFORMATION DISPLAY
The 2.1" LCD screen on the water block displays the CPU temperature, fan speed, and PUMP speed scales to monitor essential system status in real time. The CHIONE CAST LITE software enables full customization of charts and temperature unit displays (°C/°F).EXCLUSIVE IN-LINE PWM PUMP
The patented in-line pump comes with PWM control, providing stable yet powerful liquid circulation to cool down the CPU temperature efficiently while creating minimal vibrations for a silent and steady operation.NEXT GENERATION RADIATOR
The 32mm thick radiator features much denser radiator fins for improved cooling performance, the increase in dissipation surface allows the radiator to provide excellent noise-normalized performance.PERFORM IN STYLE
Built with an emphasis on superior airflow performance, the PWM fans operate up to 2000 RPM and provide airflow of up to 69.01 CFM. The fans feature hydraulic bearings for silent operations and fully addressable low-profile ARGB lighting providing a modish look with a long lifespan.SYNCHRONIZE YOUR SETUP
For stunning and customizable ARGB lighting effects, the CHIONE M4 series requires connection to the motherboard via 3-pin 5V ARGB headers. It's also compatible with the GAMDIAS AEOLUS BOX and mainstream RGB software.ROTATABLE CPU WATER BLOCK
The water block is rotatable in 360°, allowing hassle-free installation without worrying about aesthetics. Connect the USB cable prior to adjusting the screen's orientation.REAL-TIME SYSTEM MONITORING
CHIONE CAST LITE software allows you to customize display mode, temperature units, setting up the highest fan and pump speeds, as well as disable the speed scale.UNIVERSAL COMPATIBILITY
The CHIONE M4 AIO cooler comes with upgraded mounting kits for an easy installation on both the AMD and Intel platforms. (LGA 1700, AM5 ready)
GAMDIAS CHIONE M4-420 ELITE LIQUID COOLER , Support LGA 1700 / AM5 , LCD Display , PWM Pump , ARGB Motherboard Sync – BLACK
GAMDIAS CHIONE M4-420 ELITE LIQUID COOLER , Support LGA 1700 / AM5 , LCD Display , PWM Pump , ARGB Motherboard Sync , Hydraulic bearing PWM fans - BLACK
EXPERT FEATURES
- ELITE COOLING POWER
- Rotatable 2.1" LCD Displays Real-time System Information
- New Cooling Route System for Better Performance
- Patented in-line PWM Pump up to 5400 RPM
- 25%-40% Increase in Radiator Fin Thickness
- Optimized Copper Base for Better CPU Contact
- CHIONE CAST LITE Software
- ARGB Motherboard Sync
- Hydraulic bearing PWM fans
- 450mm Durable Teflon Tube
- Aesthetic Nylon-braided Tube Sleeve
- Universal Mounting Kits
- Support LGA 1700 / AM5
EXPERT SPECIFICATIONS
Model
- CHIONE M4-420
Package Contents
- Cooler ; 1
- Fan ; 3
- Thermal Grease ;M 1
- Mounting Kit ; Yes
- GAMDIAS AEOLUS BOX Adapter Cable ; 1
LIQUID COOLER - FAN
- Dimensions ; 140 x 140 x 25 mm
- Speed ; 800 - 1600 RPM±10%
- Noise Level ; 11 - 29 dBA
- Air Flow ; 90 CFM
- Air Pressure ; 1.63 mmH2O
- Bearing ; Hydraulic
- Rated Voltage12 V (Fan) / 5V(LED)
- Connector ; PWM & 5V sync
- Support PWM Control ; Yes
LIQUID COOLER
- Radiator Dimensions454 x 139 x 32 mm
- Tube Material ; Teflon
- Base Plate Material ; Copper
- Radiator Material ; Aluminum
- Sleeved Tube ; Yes
- Pump Rated Voltage ; 12 V (Pump) / 5V(LED)
- Pump Connector ; 4 Pin
- Compatibility ; LGA2066 / 2011-v3 / 2011 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1
- Support Motherboard RGB Sync Connectors ; 5V 3-pin addressable (digital) RGB header Only
FROM THE MANUFACTURER :
ELITE COOLING POWER
The CHIONE M4-420 liquid cooler delivers powerful cooling for your CPU through its patented in-line PWM pump, a 32mm thick radiator, and three 140mm ARGB fans to reach new levels of coolness. It also features a 2.1" LCD screen on the water block that displays CPU temperature, fan speed, and pump speed stats in real-time.REAL-TIME SYSTEM INFORMATION DISPLAY
The 2.1" LCD screen on the water block displays the CPU temperature, fan speed, and PUMP speed scales to monitor essential system status in real time. The CHIONE CAST LITE software enables full customization of charts and temperature unit displays (°C/°F).EXCLUSIVE IN-LINE PWM PUMP
The patented in-line pump comes with PWM control, providing stable yet powerful liquid circulation to cool down the CPU temperature efficiently while creating minimal vibrations for a silent and steady operation.NEXT GENERATION RADIATOR
The 32mm thick radiator features much denser radiator fins for improved cooling performance, the increase in dissipation surface allows the radiator to provide excellent noise-normalized performance.PERFORM IN STYLE
Built with an emphasis on superior airflow performance, the PWM fans operate up to 1600 RPM and provide airflow of up to 90 CFM. The fans feature hydraulic bearings for silent operations and fully addressable low-profile ARGB lighting providing a modish look with a long lifespan.SYNCHRONIZE YOUR SETUP
For stunning and customizable ARGB lighting effects, the CHIONE M4 series requires connection to the motherboard via 3-pin 5V ARGB headers. It's also compatible with the GAMDIAS AEOLUS BOX and mainstream RGB software.ROTATABLE CPU WATER BLOCK
The water block is rotatable in 360°, allowing hassle-free installation without worrying about aesthetics. Connect the USB cable prior to adjusting the screen's orientation.REAL-TIME SYSTEM MONITORING
CHIONE CAST LITE software allows you to customize display mode, temperature units, setting up the highest fan and pump speeds, as well as disable the speed scale.UNIVERSAL COMPATIBILITY
The CHIONE M4 AIO cooler comes with upgraded mounting kits for an easy installation on both the AMD and Intel platforms. (LGA 1700, AM5 ready)
GAMDIAS CHIONE P3-240U BLACK LIQUID COOLER WITH LCD
CHIONE-P3-240U
GAMDIAS CHIONE P3-240U BLACK LIQUID COOLER WITH LCD
https://youtu.be/LsazpEU3T8s
IPS LCD Screen
Customize LCD Background (png / gif / jpg)
Micro-embedded Fan for Motherboard Cooling
CHIONE CAST Software
LCD Screen Orientation
Control Lighting Effects / Brightness / Speed / Direction
Show System Information (with customized image)
Motherboard sync ARGB
Durable Teflon Tube with Aesthetic Nylon-braided Tube Sleeve
High Static Pressure Hydraulic PWM fan
USB AEOLUS Box
Support LGA 1700 / AM5 / TR4
LIQUID COOLER - FAN
- Dimensions 120 x 120 x 25 mm
- Speed 800 - 2000 RPM±10%
- Noise Level 10 - 31 dBA
- Air Flow 69.01 CFM
- Air Pressure 2.37 mmH2O
- Bearing Hydraulic
- Rated Voltage 12 V (Fan) / 5V(LED)
- Connector 8 pin
- Support PWM Control Yes
LIQUID COOLER
- Radiator Dimensions 277 x 119 x 27 mm
- Tube Material Teflon
- Base Plate Material Copper
- Radiator Material Aluminum
- Sleeved Tube Yes
- Pump Rated Voltage 12 V (Pump) / 5V(LED)
- Pump Connector 3 Pin
- Compatibility LGA2066 / 2011-v3 / 2011 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 / TR4
- TDP 270W ±10%
- Support Motherboard RGB Sync Connectors 5V 3-pin addressable (digital) RGB header Only
LIQUID COOLER - CONTROL BOX
- Model USBAEOLUS Box
- Dimensions 83 x 59 x 14 mm
- Power Connector SATA
- Support LED type 5V 3-pin Addressable (Digital) LED
- Support Daisy Chain Yes
- Built-In Magnet Yes
GAMDIAS CPU Air Cooler BOREAS M2-510 PWM 120 mm Fan Heatsink with 5 Heat pipes – BLACK
CPU Air Cooler BOREAS M2-510 PWM 120 mm Fan Heatsink with 5 Heatpipes Universal Socket Mounting Kits Hydraulic Bearing
EXPERT FEATURES
- Matte Black Finish
- Diamond Gradient Top Cover
- 5 Copper Heat Pipes with Direct Contact Technology
- High Cooling Performance Thick Base Plate
- 120mm Hydraulic Bearing PWM Fan with 72.94 CFM, 2.63mmH2O
- Compatible with 158mm Height
- Universal Mounting Kits, Support LGA 1700 / AM5
- PRIME PERFORMANCE
EXPERT SPECIFICATIONS
Model : BOREAS M2-510
Package Contents
- Air Cooler PWM 120 mm Fan：1
- Single Heatsink with 5 Heatpipes：1
- Thermal Grease：1
- Universal Socket Mounting Kits
AIR COOLER - FAN
- Fan Dimensions ; 120 x 120 x 25 mm
- Fin Material ; Aluminum
- Fan Speed ; 800-1800 RPM ±10%
- Air Flow ; 72.94 CFM
- Air Pressure ; 2.63 mmH2O
- Noise Level 10-32 dBA
- Bearing ; Hydraulic
AIR COOLER
- Heatpipe Material ; Copper
- Product Dimensions ; 120 x 73 x 155 mm
- Connector ; 4 Pin PWM
- Rated Voltage ; 12 V (Fan)
- Compatibility ; LGA1700/1151/1150/1155/1156/1200/2011/2066/AM5/AM4
FROM THE MANUFACTURER
PRIME PERFORMANCE
The BOREAS M2-510 Series, available in matte black and snow white, features 5 advanced copper heat pipes with direct contact technology, a thick copper base plate, one 120mm high-performance hydraulic bearing PWM fan, and finished with a sleek diamond-shaped mesh gradient top cover to integrate top cooling performance with sleek aesthetics.SLEEK AND POWERFUL
BOREAS M2-510 is made with upgraded heat pipes and fins to provide powerful and efficient cooling while maintaining a premium look. Layered in an all-black coating and a diamond-shaped gradient top cover, it is a perfect solution for modern mainstream systems.PREMIUM COOLING SOLUTION
The cooler is equipped with five advanced copper heat pipes with direct contact technology, a thick base plate for increased performance, and a bigger surface area for more efficient heat transfer.SILENT AND POWERFUL
The unit is equipped with a 120mm high-quality fan that can provide airflow up to 72.94 CFM and a static pressure of 2.63mmH2O. With premium hydraulic bearing and PWM function, the fan ensures up to 1800RPM in silent operation.FULL DRAM CLEARANCE
This CPU cooler provides unobstructed access to DIMM slots which enables users to easily upgrade on both Intel and AMD motherboards.UNIVERSAL COMPATIBILITY
The BOREAS M2-510 Series comes with the GAMDIAS Universal Mounting Kit for easy installs on both the latest Intel and AMD platforms. (LGA 1700/AM5)
GAMDIAS CPU Air Cooler BOREAS M2-510 PWM 120 mm Fan Heatsink with 5 Heat pipes – WHITE
CPU Air Cooler BOREAS M2-510 WHITE ; 120 mm Fan Heatsink with 5 Heatpipes Universal Socket Mounting Kits Hydraulic Bearing
EXPERT FEATURES
- Snow White Finish
- Diamond Gradient Top Cover
- 5 Copper Heat Pipes with Direct Contact Technology
- High Cooling Performance Thick Base Plate
- 120mm Hydraulic Bearing PWM Fan with 72.94 CFM, 2.63mmH2O
- Compatible with 158mm Height
- Universal Mounting Kits, Support LGA 1700 / AM5
- PRIME PERFORMANCE
EXPERT SPECIFICATIONS
Model : BOREAS M2-510
Package Contents
- Air Cooler PWM 120 mm Fan：1
- Single Heatsink with 5 Heatpipes：1
- Thermal Grease：1
- Universal Socket Mounting Kits
AIR COOLER - FAN
- Fan Dimensions ; 120 x 120 x 25 mm
- Fin Material ; Aluminum
- Fan Speed ; 800-1800 RPM ±10%
- Air Flow ; 72.94 CFM
- Air Pressure ; 2.63 mmH2O
- Noise Level 10-32 dBA
- Bearing ; Hydraulic
AIR COOLER
- Heatpipe Material ; Copper
- Product Dimensions ; 120 x 73 x 155 mm
- Connector ; 4 Pin PWM
- Rated Voltage ; 12 V (Fan)
- Compatibility ; LGA1700/1151/1150/1155/1156/1200/2011/2066/AM5/AM4
FROM THE MANUFACTURER
PRIME PERFORMANCE
The BOREAS M2-510 Series, available in matte black and snow white, features 5 advanced copper heat pipes with direct contact technology, a thick copper base plate, one 120mm high-performance hydraulic bearing PWM fan, and finished with a sleek diamond-shaped mesh gradient top cover to integrate top cooling performance with sleek aesthetics.SLEEK AND POWERFUL
BOREAS M2-510 is made with upgraded heat pipes and fins to provide powerful and efficient cooling while maintaining a premium look. Layered in an all-WHITE coating and a diamond-shaped gradient top cover, it is a perfect solution for modern mainstream systems.PREMIUM COOLING SOLUTION
The cooler is equipped with five advanced copper heat pipes with direct contact technology, a thick base plate for increased performance, and a bigger surface area for more efficient heat transfer.SILENT AND POWERFUL
The unit is equipped with a 120mm high-quality fan that can provide airflow up to 72.94 CFM and a static pressure of 2.63mmH2O. With premium hydraulic bearing and PWM function, the fan ensures up to 1800RPM in silent operation.FULL DRAM CLEARANCE
This CPU cooler provides unobstructed access to DIMM slots which enables users to easily upgrade on both Intel and AMD motherboards.UNIVERSAL COMPATIBILITY
The BOREAS M2-510 Series comes with the GAMDIAS Universal Mounting Kit for easy installs on both the latest Intel and AMD platforms. (LGA 1700/AM5)
GAMDIAS HELIOS E1-600 NON-MODULAR 600W PSU ATX12V v2.4 80% efficiency C6/C7 power state , 620mm EPS Cable , Automatic Fan Speed Optimization , Stealth Black
E1-600 NON-MODULAR 600W PSU
EXPERT FEATURES
- Support C6/C7 Power States & Meets 80% Efficiency : The HELIOS E1-600W can deliver up to 80%+ efficiency reliably while automatically adjusting its fan speed according to temperature.
- EXTRAORDINARY EFFICIENCY WITH 620mm EPS Cable : HELIOS E1-600W can perfectly draw power at 80% efficiency while releasing minimal heat. With less heat generated, less noise arises.
- Stealth Black : The stealthy PSU provides durability and luxury while being exceptionally economically competent.
- SMART VENTILATION : The power supply unit supports automatic fan speed optimization which adjusts its fan speed according to the temperature and load
EXPERT SPECIFICATION
- Model : HELIOS E1-600
- POWER Type : ATX12V v2.4
- Efficiency : Meeting up to 80% efficiency
- Support MB Sync : No
- Dimension (L x W x H) : 140 x 150 x 86 mm
- Support C6/C7 power state : Yes
- AC Input : 220-240V / 6A / 47-63Hz
- DC Output : +3.3V / +5V / +12V / -12V / +5Vsb
- Max. Output Current : 16A / 16A / 40.5A / 0.3A / 2.5A
- Max. Output Power : 100W / 486W / 3.6W / 12.5W
- Total Power : 600W
- Protection : OVP / UVP / OPP / SCP
- Main Power : 1 (20+4 Pin)
- CPU : 1 (4+4 Pin)
- PCI-E : 2 (6+2 Pin)
- SATA : 5 (5 Pin)
- Molex : 2 (4 Pin)
- Floppy : 1 (4 Pin)
- Modular : Non Modular
- Silent Mode : No
- DC to DC : No
GAMDIAS HELIOS M1-850B PSU 850W 80 PLUS Bronze Efficiency , APFC with PF value of 0.99 , C6/C7 Power States , Automatic Fan Speed Optimization , Black Flat Cables , Stealth Black
HELIOS M1-850B PSU 850W 80 PLUS Bronze
EXPERT FEATURES
SMART AND RELIABLE
The HELIOS M1-850B is a high quality stealth fan that can deliver up to 85% efficiency while automatically adjusting its fan speed according to temperature. It also has a high build quality with its flat black cables and 80 PLUS bronze certification.80 PLUS BRONZE CERTIFIED
Efficiency rating reflects how much power is retained on transfer, not build quality. HELIOS M1-850B, with an 80 PLUS Bronze efficiency rating, is a safe and lasting first-rate power supply unit.SMART VENTILATION
The power supply unit supports automatic fan speed optimization which adjusts its fan speed according to the temperature and load.FLAT BLACK CABLES
The stealthy and flexible black cables are designed for easy cable installation, reducing clutter, and increase the airflow within the case.
EXPERT SPECIFICATIONS
- Model : HELIOS M1-850B
- POWER : TypeATX12V v2.4
- Efficiency : Meet 80 PLUS Bronze efficiency
- Power Factor Correction : APFC with PF value of 0.99
- Support MB Sync : No
- Dimension (L x W x H) : 140 x 150 x 86 mm
- Support C6/C7 power state : Yes
- AC Input : 100-240V / 5.5-11A / 47-63Hz
- DC Output : +3.3V / +5V / +12V / -12V / +5VsbMax. Output Current : 20A / 20A / 70A / 0.3A / 2.5A
- Max. Output Power : 130W / 840W / 3.6W / 12.5W
- Total Power : 850W
- Protection : OVP / UVP / OPP / OCP / SCP / SP / ICP
- Main Power : 1 (20+4 Pin)
- CPU : 2 (4+4 Pin)
- PCI-E : 4 (6+2 Pin)
- SATA : 6 (5 Pin)
- Molex : 4 (4 Pin)
- Modular : Non Modular
- Flat Cable : Yes
- Silent Mode : No
- DC to DC : Yes
GAMDIAS HELIOS P1A-750G 750W 80 Plus Gold PSU , 120mm Hydraulic Bearing Fan , ATX12V v2.52 , C6/C7 Power State , Automatic Fan Speed Optimizing , Full DC-DC, LLC Resonant , Heavy-duty Protection: OVP/UVP/OPP/SCP/OCP/OTP – BLACK
P1A-750G 750W 80 Plus Gold PSU
EXPERT FEATURES
POWERFUL. EFFICIENT. STABLE.
- Certified with 80 PLUS GOLD, the HELIOS P1A-750G can deliver a stable output of up to 90% efficiency and reduce power consumption.
- It features black flat cables for easy installation and cable management and is equipped with high-quality capacitors and a hydraulic bearing fan to perform reliably at top conditions.
80 PLUS GOLD CERTIFIED
- With an 80 PLUS GOLD certification, the unit guarantees stable power output at up to 92% efficiency at 50% load while reducing considerable power consumption.
SMART HYDRAULIC FAN
- Equipped with a 120mm hydraulic bearing fan, the PSU ensures silent and stable operations for long durations.
- The fan also features automatic fan speed optimization, enabling the fan speed to be adjusted based on the detection of temperature and load.
LLC RESONANT CIRCUIT LAYOUT
- Made with DC to DC structure with full bridge LLC resonance assist and 12V synchronous rectification providing a safe and stable output.
FLAT BLACK CABLES
- The sleek and flexible black cables are designed for easy cable installation, reducing clutter, and increase the airflow within the case.
HEAVY-DUTY PROTECTION
- This PSU offers complete protection, meeting full demands to help the system operate safely and stably.
EXPERT SPECIFICATIONS
- Model : HELIOS P1A-750G
- POWER : TypeATX12V v2.52
- Efficiency : Meet 80 PLUS Gold efficiency
- Power Factor Correction : APFC with PF value of 0.99
- Support MB Sync : No
- Dimension (L x W x H) : 140 x 150 x 86 mm
- Support C6/C7 power state : Yes
- AC Input : 100-240V~ / 10A / 50-60Hz
- DC Output : +3.3V / +5V / +12V / -12V / +5Vsb
- Max. Output Current : 22A / 22A / 62.5A / 0.3A / 3A
- Max. Output Power : 120W / 750W / 3.6W / 15W
- Total Power : 750W
- Peak Power : 975W
- Protection : OVP / UVP / OPP / SCP / OCP / OTP
- Main Power : 1 (24 Pin)
- CPU : 1 (4+4 Pin)
- PCI-E : 2 (6+2 Pin)
- SATA : 4 (5 Pin)
- Molex : 3 (4 Pin)
- Modular : Non Modular
- Flat Cable : Yes
- Cooling System : 120mm hydraulic bearing fan
- Silent Mode : No
- DC to DC : Yes
- Environmental Compliance : Erp Lot 6
GAMDIAS MARS E2 MICROTOWER TG*1 / FAN*1 WHITE CASE
GAMDIAS-MARS-E2
GAMDIAS MARS E2 MICROTOWER TG*1 / FAN*1 WHITE CASE
Modern and Elegant Full Metal Exterior Design
I/O Port on the Side Panel is convenient to operate with
Snowy White Painted Case
Sync wiht 5V ARGB Motherboard
Tempered Glass Panels with Swing Door Design
Supports Motherboards up to micro ATX
Power Cover Design
Magnetic Dust Filter
CASE
- Case Type Micro Tower
- MB Support Mini-ITX、Micro-ATX
- Synchronization 5V 3-Pin Addressable Header
- CASE Color White
- Expansion Slots 4
- Material SPCC & ABS & Tempered Glas & Steel
- Window Left
- Radiator Support Top: 280mm、240mm / Front: 280mm、240mm / Rear: 120mm
- Fan Support Top: 2 x 120mm 、2 x 140mm / Front: 2 x 120mm、2 x 140mm / Rear: 1 x 120mm
- Pre-installed Fans Rear: 1 x 120mm Fan
- Drive Bays 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage) / 2 x 2.5"
- I/O Port USB 3.0 x2、HD Audio x1、Reset x1
- Clearance CPU cooler height limitation: 165mm VGA length limitation: 350mm PSU length limitation: 160mm
- Dimension (L x W x H) 397 x 210 x 425mm
- Net Weight 5.6 kg / 12.43 lb
GAMDIAS NESO P1 BR FULLTOWER TG*2 BLACK RED CASE
NESO-P1-BR
GAMDIAS NESO P1 BR FULLTOWER TG*2 BLACK RED CASE " FANS NOT INCLUDED"
Trapezoid Shaped for Horizontal Desktop and Vertical Tower Setup
8 Slot Horizontal and Vertical GPU Holder
Takes GPU Length up to 426mm
Supports Radiators up to 360mm, and 420mm Side
70mm of Space for Thicker Top Radiator and Fans
80mm of Space for Thicker Side Radiator and Fans
Front and Side Panoramic Tempered Glass Panels Swing Open
Dual-chamber Chassis
Room for PSU Length up to 180mm
Dimensions: 490 x 310 x 495 mm
CASE
- Case Type FULL Tower
- MB Support EATX、ATX、Micro-ATX、Mini-ITX
- Synchronization 5V 3-Pin Addressable Header
- CASE Color Black Red
- Expansion Slots 8 to 8
- Material SPCC & ABS & Tempered glass
- Window Front, Left
- Radiator Support Top: 360mm、280mm / Side: 360mm、420mm / Rear: 120mm
- Fan Support Top: 3 x 120mm、2 x 140mm / Side: 3 x 120mm、 3 x 140mm / Rear: 1 x 120mm / Bottom: 3 x 120mm
- Drive Bays 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage) 2 x 2.5"(HDD Cage) + 3 x 2.5'' (SSD Bracket)
- I/O Port USB 3.0 x2, Type C x 1, HD Audio x1, LED Control x1
- Clearance CPU cooler height limitation:193mm VGA length limitation:426mm VGA width limitation: 192mm PSU length limitation:180mm
- Dimension (L x W x H) 490 x 310 x 495 mm
- Net Weight 11.97 kg / 26.38 lb
GAMDIAS NESO P1 BW FULLTOWER TG*2 BLACK WHITE CASE
NESO-P1-BW
GAMDIAS NESO P1 BW FULLTOWER TG*2 BLACK WHITE CASE "FANS NOT INCLUDED"
Trapezoid Shaped for Horizontal Desktop and Vertical Tower Setup
8 Slot Horizontal and Vertical GPU Holder
Takes GPU Length up to 426mm
Supports Radiators up to 360mm, and 420mm Side
70mm of Space for Thicker Top Radiator and Fans
80mm of Space for Thicker Side Radiator and Fans
Front and Side Panoramic Tempered Glass Panels Swing Open
Dual-chamber Chassis
Room for PSU Length up to 180mm
Dimensions: 490 x 310 x 495 mm
CASE
- Case Type FULL Tower
- MB Support EATX、ATX、Micro-ATX、Mini-ITX
- Synchronization 5V 3-Pin Addressable Header
- CASE Color Black White
- Expansion Slots8 to 8
- Material SPCC & ABS & Tempered glass
- Window Front, Left
- Radiator Support Top: 360mm、280mm / Side: 360mm、420mm / Rear: 120mm
- Fan Support Top: 3 x 120mm、2 x 140mm / Side: 3 x 120mm、 3 x 140mm / Rear: 1 x 120mm / Bottom: 3 x 120mm
- Drive Bays 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage) 2 x 2.5"(HDD Cage) + 3 x 2.5'' (SSD Bracket)
- I/O Port USB 3.0 x2, Type C x 1, HD Audio x1, LED Control x1
- Clearance CPU cooler height limitation:193mm VGA length limitation:426mm VGA width limitation: 192mm PSU length limitation:180mm
- Dimension (L x W x H) 490 x 310 x 495 mm
- Net Weight 11.97 kg / 26.38 lb
