GAMDIAS NESO P1 W FULLTOWER TG*2 WHITE CASE
NESO-P1-W
GAMDIAS NESO P1 W FULLTOWER TG*2 WHITE CASE
Trapezoid Shaped for Horizontal Desktop and Vertical Tower Setup
8 Slot Horizontal and Vertical GPU Holder
Takes GPU Length up to 426mm
Supports Radiators up to 360mm, and 420mm Side
70mm of Space for Thicker Top Radiator and Fans
80mm of Space for Thicker Side Radiator and Fans
Front and Side Panoramic Tempered Glass Panels Swing Open
Dual-chamber Chassis
Room for PSU Length up to 180mm
Dimensions: 490 x 310 x 495 mm
CASE
- Case Type FULL Tower
- MB Support EATX、ATX、Micro-ATX、Mini-ITX
- Synchronization 5V 3-Pin Addressable Header
- CASE Color White
- Expansion Slots 8 to 8
- Material SPCC & ABS & Tempered glass
- Window Front, Left
- Radiator Support Top: 360mm、280mm / Side: 360mm、420mm / Rear: 120mm
- Fan Support Top: 3 x 120mm、2 x 140mm / Side: 3 x 120mm、 3 x 140mm / Rear: 1 x 120mm / Bottom: 3 x 120mm
- Drive Bays 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage) 2 x 2.5"(HDD Cage) + 3 x 2.5'' (SSD Bracket)
- I/O Port USB 3.0 x2, Type C x 1, HD Audio x1, LED Control x1
- Clearance CPU cooler height limitation:193mm VGA length limitation:426mm VGA width limitation: 192mm PSU length limitation:180mm
- Dimension (L x W x H) 490 x 310 x 495 mm
- Net Weight 11.97 kg / 26.38 lb
GAMDIAS NESO P1 WW RGB Dual-Chamber Tempered Glass Gaming PC Case , Partition Plate Cooling Technology, MODULAR ORIENTATION -PURE WHITE
NESO WW RGB Gaming Case WHITE
FANS NOT INCLUDED
GAMDIAS NESO P1 WW RGB Dual-Chamber Tempered Glass Gaming PC Case , Partition Plate Cooling Technology, RGB Lighting, LED Control Button, Dust Filter , MODULAR ORIENTATION , TWO-WAY ORIENTATION WITH DUAL CHAMBER & ONE-TOUCH OPEN – PURE WHITE
EXPERT SPECS
Case Type : FULL Tower
MB Support: E-ATX (310mm Width)、ATX、Micro-ATX、Mini-ITX
Synchronization : 5V 3-Pin Addressable Header
CASE Color : Pure White
Expansion Slots : 8 to 8
Material : SPCC & ABS & Tempered glass
Window: Front, Left
Radiator Support : Top: 360mm / Side: 360mm、420mm / Rear: 120mm
Fan Support : Top: 3 x 120mm、2 x 140mm / Side: 3 x 120mm、 3 x 140mm / Rear: 1 x 120mm / Bottom: 3 x 120mm
Drive Bays : 2 x 3.5″ or 1 x 2.5″+1 x 3.5″(HDD Cage)
2 x 2.5″(HDD Cage) + 3 x 2.5” (SSD Bracket)
I/O Port : USB 3.0 x2, Type C x 1, HD Audio x1, LED Control x1
Clearance : CPU cooler height limitation:193mm
VGA length limitation:426mm
VGA width limitation: 192mm
PSU length limitation:180mm
Dimension (L x W x H)490 x 310 x 495 mm
Net Weight : 11.97 kg / 26.38 lb
EXPERT FEATURES
Trapezoid Shaped for Horizontal Desktop and Vertical Tower Setup
8 Slot Horizontal and Vertical GPU Holder
Takes GPU Length up to 426mm
Supports Radiators up to 360mm, and 420mm Side
70mm of Space for Thicker Top Radiator and Fans
80mm of Space for Thicker Side Radiator and Fans
Front and Side Panoramic Tempered Glass Panels Swing Open
Dual-chamber Chassis
Room for PSU Length up to 180mm
Dimensions: 490 x 310 x 495 mm
FROM THE MANUFACTURER

PRIME LIFESTYLE CASE
The NESO P1 full-tower case features a dual-chamber design and a distinctive trapezoidal form .That allows you to showcase your hardware in either horizontal or vertical orientation.
Improve your building experience by using the one-touch mechanism to easily remove the glass and gain access to the inside for upgrades and maintenance.
The high-end chassis provide robust functionalities and features for enthusiasts, gamers, and professionals.

LIFESTYLE DESIGN
The NESO P1 comes out as a lifestyle case with its distinctive trapezoidal appearance and a sleek grid design from the inside-out.

MODULAR ORIENTATION
The case utilizes modular pedestals to rotate the case from vertical to horizontal seamlessly while leveraging solid airflow and stability.
A new case orientation provides a fresher look and unlocks an entirely new building experience.

FULL PANORAMIC DISPLAY
displays all of your hardware thanks to its unique trapezoidal form factor while concealing unsightly cables and components.
ONE-TOUCH RELEASE MECHANISM
Access your hardware with ease with a simple touch of a button.
The dual-hinged tempered glass side panels are detachable for an improved modding experience.

NEXT-LEVEL AIRFLOW DESIGN
Through fully perforated mesh panels around the case, the .NESO P1 provides optimum airflow routes and endless options to configure airflow intake and exhaust while utilizing the modular case orientation.

ROTATABLE PCIe SLOTS
NESO P1 features 8×8 rotatable PCIe slots and interior space of up to 426mm allowing flexible installation of horizontal and vertical GPUs of up to RTX 40-series.

EXCELLENT CABLE MANAGEMENT
The case’s hidden compartment is 90mm deep, allowing for ample cable management as well as a well-designed cable routing system with included velcro straps.
MODERN FRONT PANEL I/O
The concise I/O features USB 3.2 Gen 2 Type-C port, two USB 3.0 ports, and an integrated audio jack.

EXTENSIVE COOLING CAPABILITY
The side of the case is compatible with up to 420mm radiators and features an increased depth of 80mm for extra thick radiators and next-generation configurations.
EFFORTLESS INSTALLATION
The case is equipped with a detachable top cooling bracket for easy installation of top-side radiators up to 280/360mm in length.

FAN CAPACITY
NESO P1 is able to house up to 10 fans, providing a wider range of build customizability for professionals and enthusiasts.

EXTENSIVE STORAGE COMPATIBILITY
The hidden compartment is able to accommodate PSU with lengths up to 180mm.
It also comes with an additional SSD bracket and allows the case to install up to 5 x 2.5″ SSD, or up to 2 x 3.5″ HDD.

MASSIVE INTERIOR
Ready for the next-gen configurations and hardware. NESO P1 supports E-ATX motherboards with widths up to 310 mm, and VGA cards with lengths up to 426mm and widths up to 192 mm.

FIND YOUR IDENTITY
Available in five different color variations: black, black and white, white, red, and pure white. Choose and combine your components to create a. NESO P1 build that will stand out and best reflect you.
GAMDIAS TALOS E2 ELITE MIDTOWER TG*2 / FAN*3 BLACK CASE
GAMDIAS-TALOS-E2
GAMDIAS TALOS E2 ELITE MIDTOWER TG*2 / FAN*3 BLACK CASE
Sync with 5V ARGB Motherboard
Tempered Glass Panel
3 Built-in 120mm ARGB Fans
Left Tempered Glass Panels with Swing Door Design
One Touch to Easily Switch RGB Streaming Lighting Style
Supports Motherboards up to ATX
Power Cover Design
Magnetic Dust Filter
CASE
- Case Type MID Tower
- MB Support ATX、Micro-ATX、Mini-ITX
- Synchronization 5V 3-Pin Addressable Header
- CASE Color Black
- Expansion Slots 7+3
- Material SPCC & ABS & Tempered glass
- Window Front. Left
- Radiator Support Top: 240mm / Front: 360mm、280mm / Rear: 140mm、120mm
- Fan Support Top: 2 x 120mm、2 x 140mm / Front: 3 x 120mm、2 x 140mm、2 x200mm / Rear: 1 x 120mm 、1 x 140mm
- Pre-installed Fans Front: 3 x 120mm ARGB Fans / Rear: 1 x 120mm Fan
- Drive Bays 2 x 3.5" or 1 x 2.5" + 1 x 3.5" (HDD Cage) / 3 x 2.5"
- I/O Port USB 3.0 x1、USB 2.0 x2、HD Audio x1、LED Control x1Clearance CPU cooler height limitation: 190mm
-
VGA length limitation: 340mm
- PSU length limitation: 180mm
- Dimension (L x W x H )392 x230 x 467 mm
- Net Weight 6.2 kg/ 13.67 lb
GAMDIAS TALOS E3 MESH ELITE PC CASE , ATX Gaming Computer Cases, Mid Tower, Pre-installed 3 ARGB PWM Fans , Tempered Glass Panel, Airflow Mesh, Support Dual 360 – BLACK
GAMDIAS TALOS E3 MESH ELITE BLACK PC CASE
Expert Description
- Perforated Front Panel: The TALOS E3 MESH ELITE comes with a highly perforated front panel with 5.0mm air vents optimized to provide superior air intake and improved temperatures.
- 3 Built-in ARGB PWM Fans: Featuring two built-in 140mm PWM ARGB fans at the front and a 120mm one at the back, the case can provide exceptional lighting and fine-tuned airflow.
- Cooling Compatibility: The case supports three 120mm or two 140mm fans up front. Multiple mounting points for 360/280mm radiators up front, and at the top. The massive capacity also allows CPU cooler height up to 180mm.
- Interior Accommodation: Designed with a compact form factor, the case offers the option to house up to E-ATX motherboards and VGA cards up to 390mm.
- Gen 2 Type-C Interface: The I/O features one USB 3.2 Gen 2 Type-C port for high transfer speeds up to 10 Gbps, USB 3.0 port, fan LED controls, and additional audio connectivity.
TAL-E3MESH-EL-BK
GAMDIAS TALOS E3 MESH ELITE BLACK PC CASE
GAMDIAS TALOS E3 MESH ELITE PC CASE , ATX Gaming Computer Cases, Mid Tower, Pre-installed 3 ARGB PWM Fans , Tempered Glass Panel, Airflow Mesh, Support Dual 360 - BLACK
GAMDIAS TALOS E3 MESH ELITE WHITE PC CASE , ATX Gaming Computer Cases, Mid Tower, Pre-installed 3 ARGB PWM Fans , Tempered Glass Panel, Airflow Mesh, Support Dual 360, White
GAMDIAS TALOS E3 MESH Mid-Tower ATX Gaming CASE – PIXILLATED ARMY CAMO LIMITED EDITION – 3 Built-in 120mm ARGB Fans
TALOS E3 CASE CAMO LIMITED EDITION
GAMDIAS TALOS E3 MESH Mid-Tower ATX Gaming CASE - PIXILATED ARMY CAMO LIMITED EDITION - Tempered Glass Panel and a Magnetic Dust Filter & 3 Built-in 120mm ARGB Fans, Tool-Free Installation, Mesh Front Panel
EXPERT FEATURES
- 5.0mm Perforated Front Panel
- Sync with 5V ARGB Motherboard
- Tempered Glass Side Panel
- 3 Built-in 120mm ARGB Fans
- Tool-Free Installation Tempered Glass Window
- One Touch to Easily Switch RGB Streaming Lighting Style
- Supports Motherboards up to ATX
- Power Cover Design
- Magnetic Dust Filter
- FORGED FOR AIRFLOW
EXPERT SPECIFICATIONS
- Case Type ; MID Tower
- MB Support ; ATX、Micro-ATX、Mini-ITX
- Synchronization ; 5V 3-Pin Addressable Header
- CASE Color ; PIXILLATED ARMY CAMO LIMITED EDITION
- Expansion Slots ; 7
- Material ; SPCC & ABS & Tempered glass
- Window ; Left
- Radiator Support ; Top: 240mm / Front: 360mm ( HDD is removable to support 360 AIO in front )、280mm / Rear: 120mm
- Fan Support ; Top: 2 x 120mm / Front: 2 x 120mm、 2 x 140mm / Rear: 1 x 120mm
- Pre-installed Fans ; Front: 2 x 120mm ARGB Fans / Rear: 1 x 120mm ARGB Fan
- Drive Bays2 x 3.5" or 1 x 2.5" + 1 x 3.5" (HDD Cage) / 2 x 2.5"
- I/O Port ; USB 3.0 x1, USB 2.0 x2, HD Audio x1, Fan LED Control x1
- Clearance ; CPU cooler height limitation: 160mm VGA length limitation: 300mm PSU length limitation: 150mm
- Dimension (L x W x H)363 x 210 x 447 mm
- Net Weight4.72 kg / 10.38 lb
FROM THE MANUFACTURER " ILLUSTRATIONS ARE WITHOUT THE PIXILATED CAMO LOOK BUT THE ACTUAL PRODUCT IS CAMO CLAD "
FORGED FOR AIRFLOW
TALOS E3 MESH Series, available in matte black and snowy white , camo-black limited edition , is a mid-tower case that offers a seamless combination of compact design and airflow performance. The case features 3 built-in 120mm ARGB fans with a 5.0mm perforated front panel to leverage airflow performance while achieving a minimalist style with tempered glass side panels and a PSU cover design.VENTED FRONT PANEL
The TALOS E3 MESH comes with a highly perforated front panel with 5.0mm air vents optimized to provide superior air intake and improved temperatures.3 BUILT-IN ARGB FANS
The case is equipped with 3 built-in 120mm ARGB fans to provide robust airflow and an RGB visual feast.SHOW OFF YOUR BUILD
TALOS E3 MESH supports system-wide ARGB to compatible motherboards with lighting synchronization fully displayed by the perforated front panel and the tempered glass side panel.SIMPLE AND ACCESSIBLE
The I/O is equipped at the top front of the case, featuring 2x USB port, 1x USB 3.0 port, LED lighting controls, and additional audio connectivity.COOLING COMPATIBILITY
TALOS E3 MESH supports two 120mm or 140mm fans up front. Multiple mounting points for 360/280/240mm radiators up front, and 280/240/120mm radiator at the top.INTERIOR ACCOMMODATION
Designed with a compact form factor, the case offers the option to house up to ATX motherboards and VGA cards up to 300mm.FLEXIBLE STORAGE SOLUTION
The interior configuration has ample room for cable management optimization and supports PSU lengths up to 150mm.MAGNETIC DUST FILTER
In order to make cleaning out dust easier than ever, the case is equipped with dust filters on the top and bottom of the case.GeForce RTX 4090 24GB OC XLR8 EPIC-X RGB Gaming PNY VERTO Overclocked Triple Fan Graphics Card DLSS 3 | VCG409024TFXXPB1-O
GeForce RTX 4090 24GB OC XLR8 EPIC-X RGB
EXPERT FEATURES
- Graphics Coprocessor : NVIDIA GeForce RTX 4090
- Brand : PNY
- Graphics Ram Size : 24 GB
- GPU Clock Speed : 2235 MHz
- Video Output Interface : DisplayPort, HDMI
- NVIDIA Ada Lovelace, with 2235MHz core clock and 2565MHz boost clock speeds to help meet the needs of demanding games.
- 24GB GDDR6X (384-bit) on-board memory, plus 16384 CUDA processing cores and up to 1008GB/sec of memory bandwidth provide the memory needed to create striking visual realism.
- PCI Express 4.0 interface - Offers compatibility with a range of systems. Also includes DisplayPort and HDMI outputs for expanded connectivity.
- NVIDIA GeForce Experience - Capture and share videos, screenshots, and livestreams with friends. Keep your drivers up to date and optimize your game settings. It's the essential companion to your GeForce graphics card.
- Short board length of RTX 4090 designed for best fit in most computer chassis.
- Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
EXPERT SPECS
Brand | PNY |
---|---|
Series | VERTO OC |
Interface | PCI Express 4.0 |
---|
Chipset Manufacturer | NVIDIA |
---|---|
GPU Series | NVIDIA GeForce RTX 40 Series |
GPU | GeForce RTX 4090 |
Core Clock | 2235 MHz |
Boost Clock | 2565 MHz |
Memory Size | 24GB |
---|---|
Memory Interface | 384-Bit |
Memory Type | GDDR6X |
DirectX | DirectX 12 Ultimate |
---|---|
OpenGL | OpenGL 4.6 |
Multi-Monitor Support | 4 |
---|---|
HDMI | 1 x HDMI 2.1 |
DisplayPort | 3 x DisplayPort 1.4a |
Max Resolution | 7680 x 4320 |
---|---|
Cooler | Triple Fans |
Thermal Design Power | 450W |
Recommended PSU Wattage | 850W |
Power Connector | 1 x 16-Pin |
Max GPU Length | 332 mm |
---|---|
Card Dimensions (L x H) | 332mm x 137mm |
Slot Width | 3.5 Slot |
GIGABYTE B650M DS3H (AM5/ LGA 1718/ AMD/ B650/ Micro ATX/ DDR5/ PCIe 4.0 M.2/ PCIe 4.0/ USB 3.2 Gen2X2 Type-C/ 2.5GbE LAN/Motherboard)
GIGABYTE B650M DS3H DDR5 Motherboard
EXPERT FEATURES
- AMD AM5 Socket: Supports AMD Ryzen 7000 Series Processors
- DDR5 Compatible: 4*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
- Sturdy Power Design: Direct 6+2+1 Phases Digital VRM Solution
- Comprehensive Thermal Design: Advanced Thermal Design, M.2 Thermal Guard
- Next Gen Connectivity: PCIe 5.0, NVMe PCIe 4.0 x4 M.2, SuperSpeed USB 3.2 Gen 2x2 Type-C
- Fast Networking: 2.5GbE LAN
- Fine Tuning Features: RGB FUSION 2.0, Supports Addressable LED & RGB LED Strips, Smart Fan 6, Q-Flash Plus Update BIOS without installing, CPU, Memory, and GPU"
EXPERT SPECS
Brand | GIGABYTE |
---|---|
Model | B650M DS3H (rev. 1.0) |
Part Number | B650M DS3H (rev. 1.0) |
CPU Socket Type | AM5 |
---|---|
CPU Type | AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors |
Chipset | AMD B650 |
---|
Number of Memory Slots | 4x288pin (DDR5) |
---|---|
Memory Standard | Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / MT/s memory modules |
Maximum Memory Supported | 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
Channel Supported | Dual channel memory architecture |
ECC Supported | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
Buffer Supported | Un-buffered |
Memory Feature | Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information. |
PCI Express 4.0 x16 | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) |
---|---|
PCI Express x1 | 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) |
SATA 6Gb/s | 4 x SATA 6Gb/s |
---|---|
M.2 | 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) |
SATA RAID |
|
Audio Chipset | Realtek® Audio CODEC |
---|---|
Audio Channels |
|
Max LAN Speed | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
---|
Back I/O Ports | 4 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 2 x DisplayPorts 1 x HDMI port 1 x USB 3.2 Gen 2 Type-A port (red) 1 x USB Type-C® port, with USB 3.2 Gen 2 support 1 x Q-Flash Plus button 1 x RJ-45 port 2 x USB 3.2 Gen 1 ports 3 x audio jacks |
---|---|
PS/2 | 1 x PS/2 keyboard/mouse port |
Other Connectors |
|
---|
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 24.4cm x 24.4cm |
Windows 11 | Support for Windows 11 64-bit Support for Windows 10 64-bit |
---|
Gigabyte GeForce RTX 3070 Vision OC 8G 256-bit GDDR6 (USED)
Gigabyte GP-P850GM (80 Plus Gold 850W, Modular, Smart Fan, Smart Power Protection, Power Supply)
GIGABYTE H610M H DDR4 MOTHERBOARD
GIG-H610-H-DDR4
-
CPU
- LGA1700 socket: Support for 13th Generation Intel® Core™ Processors and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors*
- L3 cache varies with CPU
-
Chipset
- Intel® H610 Express Chipset
-
Memory
- Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
- 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
- Dual channel memory architecture
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for Extreme Memory Profile (XMP) memory modules
-
Onboard GraphicsIntegrated Graphics Processor-Intel® HD Graphics support:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports
-
Audio
- Realtek® Audio CODEC
- High Definition Audio
- 2/4/5.1/7.1-channel You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
-
LAN
- Intel® GbE LAN chip (1 Gbps/100 Mbps)
-
Expansion Slots
- 1 x PCI Express x16 slot, running at x16 * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCI Express x16 slot conforms to PCI Express 4.0 standard.)
- 1 x PCI Express x1 slot (The PCI Express x1 slot conforms to PCI Express 3.0 standard.)
-
Storage InterfaceChipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
- 4 x SATA 6Gb/s connectors
-
USBChipset:
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 4 x USB 2.0/1.1 ports on the back panel
- 4 x USB 2.0/1.1 ports available through the internal USB headers
-
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x M.2 Socket 3 connector
- 4 x SATA 6Gb/s connectors
- 1 x CPU fan header
- 2 x system fan headers
- 1 x RGB LED strip header
- 1 x front panel header
- 1 x front panel audio header
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0/1.1 headers
- 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
- 1 x serial port header
- 1 x Clear CMOS jumper
-
Back Panel Connectors
- 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 1 x D-Sub port
- 1 x HDMI 2.0 port
- 2 x USB 3.2 Gen 1 ports
- 4 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 3 x audio jacks
-
I/O Controller
- iTE® I/O Controller Chip
-
H/W Monitoring
- Voltage detection
- Temperature detection
- Fan speed detection
- Overheating warning
- Fan fail warning
- Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install.
-
BIOS
- 1 x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
-
Unique Features
- Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS Ambient LED EasyTune Smart Backup System Information Viewer
- Support for Q-Flash
- Support for Xpress Install
GIGABYTE P650B GP-P650B 650 W PSU Intel Form Factor ATX 12V v2.31 80 PLUS BRONZE Certified Non-Modular Active PFC (>0.9 typical) PFC Power Supply
650 W 80 PLUS BRONZE PSU
EXPERT FEATURES
- Intel Form Factor ATX 12V v2.31
- Non-Modular
- 80 PLUS BRONZE Certified
- 100 - 240 V 50/60 Hz
- +3.3V@18A, +5V@15A, +12V@54A, -12V@0.3A, +5VSB@2.5A
- 80 PLUS bronze certified: up to 89% efficiency
- 100% Japanese Capacitors
- 120mm Hydraulic Bearing (HYB) Fan
- Single +12V rail
- Meet ErP LOT6 2013 (< 0.5W at standby mode)
- OPP/UVP/OVP/SCP/OCP protection
EXPERT SPECS
Brand | GIGABYTE |
---|---|
Series | P650B |
Model | GP-P650B |
Type | Intel Form Factor ATX 12V v2.31 |
---|---|
Maximum Power | 650 W |
Fans | 1 x 120mm Hydraulic Bearing Fan |
PFC | Active PFC (>0.9 typical) |
Main Connector | 20+4Pin |
+12V Rails | Single |
PCI-Express Connector | 4 x 6+2-Pin |
SATA Power Connector | 6 |
Max PSU Length | 140 mm |
Modular | Non-Modular |
Efficiency | Up to 85% at typical load |
Energy-Efficient | 80 PLUS BRONZE Certified |
Over Voltage Protection | Yes |
Protection | OPP / UVP / OVP / SCP / OCP |
Input Voltage | 100 - 240 V |
Input Frequency Range | 50/60 Hz |
Input Current | 9A - 4A |
Output | +3.3V@18A, +5V@15A, +12V@54A, -12V@0.3A, +5VSB@2.5A |
MTBF | >100,000 Hours |
Approvals | CE/ CCC/ BSMI/ KCC/ EAC/ UL/ TUV/ RCM/ FCC/ PSE |
Connectors |
|
Features | 80 PLUS bronze certified: up to 89% efficiency 100% Japanese Capacitors 120mm Hydraulic Bearing (HYB) Fan Single +12V rail Meet ErP LOT6 2013 (< 0.5W at standby mode) OPP/UVP/OVP/SCP/OCP protection |
---|
Dimensions | 3.39" x 5.51" x 5.91" |
---|
