GVISION 10/100/1000M Uplink Port switch poe support switch poe reverse and poe switch 8 port
1*10/100/1000M Uplink Port switch poe support switch poe reverse and poe switch 8 port
PRODUCT INTRODUCTION:
RPOE switch has intelligent device Power management features solving a major problem of powering the device for internet service provider.
This switch can be powered using remote power from customer using specially designed POE injector or any standard POE injector(24v DC,0.75amp).
This eliminates the needs of arranging power at building top (ups not require/No need to pay more money to customer or society).This saves lot of money of ISPs and improves uninterrupted service to the customer.
PRODUCT FEATURE:
REVERSE POE TECHNOLOGY:7Port 10/100+ 1G Reverse POE switch which has latest generation of fast Ethernet reverse POE switching technology. It contains 7*10/100 base T Reverse Poe ports (RPOE),1*10/100/1000 Base date Uplink Port&12V DC out for Powering ONU.
Supports Auto-Negotiation: Each of the ports automatically detect whether connected network devices are running at 10Mbps or 100Mbps (Up-link Port is 1000Mbps) and half-duplex or full-duplex mode, and adjusts the speed and mode accordingly ensuring easy and hassle-free operation.
Supports Non-blocking Wire Speed: The switch forwards and receives traffic seamlessly with its Non-blocking wire- speed. Every port of the Switch supports speeds up to 200Mbps(Up-link Port is 2000Mbps)in full-duplex mode simultaneously, providing full wire speed to connected devices and allowing you to run a high speed network smoothly.
Cascading support: switches can be cascaded for more users per Building (Up to 1 Main+3 switches )
Port base Isolation u/Hardware VLAN: The feature of Port Isolation is implemented in this unit where in the Ethernet Date of the Uplink Port can be transferred to any of the Downlink ports but the individual Downlink ports cannot communicate with each other.
Over voltage Protection: Over voltage Protection is provided on each date port to eliminate damage due to connection of higher voltage(Higher than 24V DC. Up to 30V DC). By mistake if user connect more than 24V POE injector then switch will goes on power off mode and will start working again once this high voltage source is removed.
Over current Protection: We have provided over current protection on each port to prevent damage to the switch in case of high current flowing due to any reason. This is provided using Resettable Fuse to facilitate easy maintenance and avoiding frequent change of blown fuse.
PRODUCT APPLICATION:
7*10/100 Base T Reverse POE Ports(RPOE) & 1*10/100/1000 Base T Uplink Port & 12V DC Power out for Powering ONU
PRODUCT SPECIFICTAION:
| Product | RPOE 7*10/100M+1*1000M 12V2A out |
| Ethernet Connector | RJ45 Jacks(8 Ports)10/100Base-TX with Auto-MDIX |
| 1*10/100/1000M Base T Data Uplink Port(port 1) | |
| 7*10/100 Base-Reverse POE Ports(Port 2to 8)Data + Power in | |
| standards | IEEE STD. 802.3 10BASE T 10Mbps,Half/Full Duplex IEEE STD. 802.3U 100BASE-TX,10/100Mbps,Half/Full Duplex IEEE STD.802.3X FLOW CONTROL AND BACK PRESSURE IEEE STD.802.3AZ Energy Efficient Ethernet |
| Protocols | CSMA/CD |
| Transmission Method | Store and forward |
| MAC ADDRESS | Support 8k MAC address |
| Packet Buffer | |
| Maximum Forwarding Packet Length | Supports 9216-byte jumbo packet length forwarding at wire speed |
| Filtering/Forwarding Rates | 1000Mbps Port – 148800pps 100Mbps Port – 14880pps 10Mbps Port – 14880pps |
| Network Cable | 4-pair UTP/STP Cat 5 cable |
| LEDs | Link/Activity per Ethernet port Power: On/Off for switch |
| Power Over Ethernet injector: Power Supply(IN) | Power over Ethernet 24V @ 18W on SPARE pair ( to supply power to the HDV switch as well as a compatible POE device(e.g. CPE) |
| No. of Ethernet Ports that can Power On the Switch & ONU | Any one /all of the seven Downlink Ports |
| Power Over Ethernet | Power over Ethernet injector on Four Pair Cable |
| DC Out | 12V/2A DC OUT THROUGH DC jack for powering other Device like ONU |
| Ethernet Devices that can be powered | Single |
| CAT-5 Cable Date Lines | Pair 1:Pins 1/2,Pair 2:Pins3/6 |
| CAT-5 Cable Power Lines | +VDC: Pins 4/5,-VDC:Pins 7/8 |
| Power consumption | 5 Watt (Poe injector) / 2 Watt (Switch) |
| Operating Temperature | 0℃to 50℃ |
| Storage environment | 0℃ to 75℃ |
| Operating Humidity | 20% to 95% (non-condensing) |
| Dimension of Switch | 125mm*70mm*25mm |
| Weight of Switch | 0.45KG |
HAP LITE MIKROTIK RB941
- The home Access Point lite (hAP lite TC) also known as RB941-2nD is an ideal little device for your apartment, house or office
- It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access
- The device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others
- The hAP lite TC is equipped with a powerful 650MHz CPU, 32MB RAM, dual chain 2.4GHz onboard wireless, four Fast Ethernet ports and a RouterOS L4 license. USB power supply is included
- CPU: QCA9533; Storage size: 16 MB; Wireless 2.4 GHz standards: 802.11b/g/n; Antenna gain dBi for 2.4 GHz: 1.5; Tested ambient temperature: -20°C to 70°C
HDMI 4Kx2K to RJ45 Extender Adaptor by Cat-6/6E Cable. Extends HDTV up to 30 meters , 2.5Gbs Signaling Rate 1080p Display (Black)
HDMI 4Kx2K to RJ45 Extender Adaptor
Expert Features
- CAT-6/6E has more flexibility and convenience in cable construction
- HDMI Extender by CAT-6/6E uses single piece CAT-6/6E cable to extend the HDTV display up to 30 meters for 1080p.
- Plug the fixed HDMI connector of the sender in to the HDMI input source such as: HD-DVD , PS3 , STB etc.
- Connect single CAT-6/6E cable to both the output of the transmitter and input of the receive.
- Plug the fixed HDMI connector of the receiver into the HDMI display ( such as : HD-LCD , HD- DLP ) One pair as a full functional module,no need of setting.
- CAT-6/6E cable can substitute HDMI cable to achieve long distance transmission.
- Signaling rate up to 2.5Gbs in support of 1080p display. No need for extra power supply.
HDMI KVM OVER IP EXTENDER WITH 2 PORTS USB
HIGH DEFINITION MULTIMEDIA INTERFACE / HDMI KVM OVER IP EXTENDER WITH 2 PORTS USB / TRANSMITTER & RECEIVER
Product Introduction 1. Modular design to assemble for Extender, Splitter, Matrix and Switcher for up to 1x256 (N TO 1 is not supported) applications. 2. Extends 4K 30P, 1080 60P HDMI signal up to 180m (600ft) over a single Cat5E cable, 100M Ethernet. 3. Use conventional Ethernet Switch for extension and distribution, and can be cascaded by the Ethernet switches for longer distance. 4. Supports IR (20KHz~60KHz) extension. 5. Supports Stereo Audio over IP, independent to HDMI extension. 6. Supports USB (Keyboard, Mouse) extension over IP and KVM switch function by button selection. 7. Supports EDID pass-through and Transmitter resolution pass-through, including most popular 16:9, 16:10, 4:3 resolution and timing (Support list please refer to appendix). 8. Supports Graphic/ Video mode selection and the latency is between 0.06-0.10 seconds. 9.Power supply is 5V2A with TYPE-C port. 10.The shell is made of aluminum alloy with fixed holes for easy installation.Note: N TO N mode means that multiple TXs are connected to multiple RXs through the Ethernet switch. Turn to SP and press the ID to pair the IDs. The indicator light of the same group should be the same and different from that of other groups Note: USB KVM supports only mouse and keyboard. Other USB devices are not supported.
Accessories INCLUDED IN THE BOX :- 1pair of HDMI extender - Power Adapter 5V/2A x 2, - IR TX Cable x 2, - IR RX Cable x 2, - USB2.0 male to male cable x 1, - User Manual X1,
Appearance size:
Length* Width * Height: 139*54*24(mm) Weight: 137g (for 1pc)
Note: Please use the original power supply of the product. If the signal is weak or intermittently interrupted, the network cable length may exceed the required range. If the mouse and keyboard are stuck, power it on again.
HDMI SMART PLUS 4×1 4K QUAD MULTI-VIEWER
4K HDMI Quad Screen Multiviewer 4x1 1080P 4 in 1 out HDMI Multi Viewer Seamless Switcher 5 Display Modes for Camera Laptop PC TV
- This 4-input HDMI multi-viewer 4K version allows you to connect four separate HDMI audio/video sources to one HDMItelevision, projector or monitor, and then display the video feeds from all four at the same time. For instance, connect a media server, Blu-ray player, security camera and Xbox to your HDTV, and watch the video transmission from all four simultaneously with built-in IR control.
- HDMI Quad-Screen MultiViewer
The 4 in 1 out HDMI multi-viewer display video from one, two or all four HDMI sources at the same time. connected up to 4 HDMI audio/video sources and displays them simultaneously on a single HDMI TV, monitor or projector.- Up to 5 Display modes
The Hdmi multiviewer switch offers multiple ways to watch your source devices, allowing you to display 1 device or all 4 devices at the same time. Display Mode 1,Mode 2,Mode 3,Mode 4.The videos will be scaled and squashed to fit the full screen4K HDMI Multi-viewer
The 4 in 1 out HDMI quad viewer supports scaler function and can support in and out resolutions up to 3840X2160@30Hz and HDCP 1.4.It can scale 1080P input signal to 3840X2160@30Hz.(Note: the resolutions refers to the figure only,the actual quality is no more than 1080P)- what's in the box
HDMI Multi-viewer X 1 Remote control X 1(no battery) Power Adapter X 1
HDMI WIRELESS EXTENDER 200-300M
Dual Antenna 660ft 1×2 Loop Out With IR HDMI Wireless Transmitter and Receiver Video Sender 1080P 3D HDMI Wireless Extender 200m~300m
HDMI extender through wireless WIFI signal transmission HD audio and video signal, at the
same time, with infrared extensions to make remote control more convenient. The equipment has
excellent image processing and transmission capacity, makes signal transmission more smooth and
steady, is a kind of economic and efficient way of HDMI signal extension.
Features
-HDMI video and audio transmission via wireless WIFI, up to 200 meters;
-HD video signal resolution up to 1920*1080 @ 60 Hz;
-HDMI 1.3 compatible
-Special format H.264 is used to compress and decompress video, effectively improve the
transfer efficiency, to ensure that the playback fluency
-In accordance with standard 1.2 HDCP, high-bandwidth digital content protection technology:
-Support external remote infrared extension, easy to operate the remote device ;
-Able to automatically identify and configure a variety of display mode;
-Built-in automatic balance system, the picture is fluent, clear and stable;
-The built-in ESD electrostatic protection circuit, comprehensive security protection system;
– Simple and convenient installation, plug and play, do not need to set up .
Package list
HDMI transmitter: 1 pcs
HDMI receiver: 1 pcs
Power adapter :2 pcs
IR TX/RX Cable : 1set
User manual: 1 pcs
HDMI WIRELESS EXTENDER 60M 1080P
Wireless HDMI Transmitter And Receiver 4K, HDMI Extender 60 METER for Streaming 5G Video Adapter From PC Laptop To HDTV, Monitor, Projector, Live TV, Conferences, Lectures (Also Support Phone, Tablet)
About this item
Make life easier - wireless hdmi transmitter and receiver can wirelessly stream audio & 4k video from laptop, tv box, ps4, dvd, camera, phone to hdtv, projector, monitor up to 60 meter transmission range
It enables you to share an Internet connection among multiple devices without extra ethernet HDMI cable
HUAWEI 8546M ONT WiFi, 1x RJ45 1000Mb/s, 3x RJ45 100Mb/s, 1x RJ11, 1x USB ROUTER ( UPC )
HUAWEI-8546M
HUAWEI 8546M ONT WiFi, 1x RJ45 1000Mb/s, 3x RJ45 100Mb/s, 1x RJ11, 1x USB ROUTER ( UPC )
Key features of Huawei EchoLife HG8546M Gpon Onu
- GPON ONT terminal
- GPON SC/UPC port
- 1 Gigabit Ethernet port
- 3 Fast Ethernet ports
- 1 USB port
- 1 phone port (POTS)
- possibility of WiFi network transmission in 2.4 GHz band
- maximum wireless transmission speed 300Mbps
- two external antennas with 2 dBi gain each
Intel Ethernet Converged Network Adapter X540-T2 10GB
10Gb PCI-E Network Card X540-T2 RJ45
EXPERT FEATURES
- Intel Ethernet Converged Network Adapter X540-T2 10GBASE-T Dual Port Passive heatsink Pie 21 (5Gt/s) Standard Cat6a cabling with RJ45 connectors
- Design that delivers high availability scalability and for maximum flexibility and price/performance
- Made in Taiwan
- Low cost low power 10 Gigabit Ethernet (10GbE) performance for the entire data center
- Standard CAT-6a cabling with RJ45 connectors
- Backward compatibility with existing 1000Base-T networks simplifies the transition to 10GbE
- Flexible I/O virtualization for port partitioning and quality of service (Qu's) of up to 64 virtual ports
Intel I225 Chipset 2.5 Gigabit Ethernet PCI Express PCI-E Network Interface Card 10/100/1000/2500 Mbps RJ45 LAN Adapter
Keystone Patch Panel 24 Port 1U Rackmount or Wall Mount UTP Unloaded Patch Panel Blank for Ethernet Cables – Multimedia Patch Panel
Patch Panel 24 Port Wall Mount
Expert Features
🌟𝗥𝗘𝗩𝗢𝗟𝗨𝗧𝗜𝗢𝗡𝗜𝗭𝗘 𝗬𝗢𝗨𝗥 𝗡𝗘𝗧𝗪𝗢𝗥𝗞 𝗠𝗔𝗡𝗔𝗚𝗘𝗠𝗘𝗡𝗧:
- Introducing the game-changing 24 port patch panel – your gateway to an entirely new level of network organization and connectivity control.
- Say goodbye to cable clutter and hello to a sleek, efficient setup that shines with 24 blank keystone ports.
🧩𝗘𝗠𝗣𝗢𝗪𝗘𝗥 𝗬𝗢𝗨𝗥 𝗡𝗘𝗧𝗪𝗢𝗥𝗞 𝗙𝗟𝗘𝗫𝗜𝗕𝗜𝗟𝗜𝗧𝗬:
- Imagine having the power to craft your network exactly as you envision.
- With our 24 port keystone patch panel adaptable keystone jacks, you hold the keys to a customizable network masterpiece.
- Build connections that fit your specific needs, whether you're optimizing for speed, reliability, or a combination of both.
🔒𝗜𝗡𝗩𝗘𝗦𝗧 𝗜𝗡 𝗙𝗨𝗧𝗨𝗥𝗘-𝗥𝗘𝗔𝗗𝗬 𝗖𝗢𝗡𝗡𝗘𝗖𝗧𝗜𝗩𝗜𝗧𝗬:
- In a world where technology evolves at lightning speed, future-proofing your network is paramount.
- Our patch panel 24 port doesn't just offer 24 ports; it offers the promise of tomorrow.
- Each port is a potential upgrade point, ensuring your network stays relevant and adaptable, no matter what innovations lie ahead.
⚙️𝗖𝗥𝗔𝗙𝗧𝗘𝗗 𝗧𝗢 𝗘𝗫𝗖𝗘𝗘𝗗 𝗘𝗫𝗣𝗘𝗖𝗧𝗔𝗧𝗜𝗢𝗡𝗦:
- Elevate your network with professional-grade quality that redefines performance standards.
- Our 1U server patch panel is meticulously engineered to minimize signal interference, guarantee secure connections, and maintain unwavering data flow.
🚀𝗦𝗜𝗠𝗣𝗟𝗜𝗙𝗬 𝗦𝗘𝗧𝗨𝗣, 𝗔𝗠𝗣𝗟𝗜𝗙𝗬 𝗣𝗥𝗢𝗗𝗨𝗖𝗧𝗜𝗩𝗜𝗧𝗬:
- We understand that time is of the essence, and every minute spent configuring your network is a minute away from your core tasks.
- That's why we've designed our ethernet patch panel for swift and hassle-free installation.
KVM HDMI 4×1 4K ULTRA HD QUAD MULTI-VIEWER
HDMI SMART PLUS KVM HDMI 4x1 4K ULTRA HD QUAD MULTI-VIEWER , 4K HDMI KVM Switch 4x1 Quad Multi Viewer 4 in 1 Out KVM HDMI Processor Screen Multiviewer Seamless for 4 PC Share Mouse Keyboard
Description
4K HDMI 4x1 Quad KVM Multi-viewer is a high performance with four HD screen segmentation and seamless switching output switch.
It can display 4 HD digital video signal on the same screen, and has a variety of video segmentation, seamless switching 4 HD input signal synchronously. The control methods of the switch is flexible, it can be switched via button , IR control and KVM control. It's a very practical and stable switch and easy to install, can be used in the major projects, meeting halls and other places.
HDMI 1.4b and HDCP1.4,4K 30Hz 1080P 4x1 HDMI Quad Multiview seamless KVM switch,4 IN 1 OUT, Five ways Viewing Screen, IR control and button control ,Hotkey switch and KVM switch.
Features:
Specifications:
Support 4HDMI input, 1 HDMI output;
Support HDMI 1.4b and HDCP 1.4
Support 4 channels HDMI signal screen segmentation;
Support 4 channels HDMI signal seamless switching;
Support resolution up to 4K@30Hz/1080@60Hz;
Support 4 USB 2.0 port and KVM control;
Support IR control;
Input support resolution:4K,1080P,720P,1080i,1024X768,1360X768 etc
Support audio output format:PCM2
Input cable distance: ≤15M AWG26 HDMI standard cable
Output cable distance: ≤24M AWG26 HDMI standard cable
Max bandwidth:330MHz
Max baud rate:10.2Gbps
Maximum working current:0.6 A
Power adapter :5V/2A
Dimension(LxWxH):148x63x23mm
Package List:
1 x HDMI 4x1 quad KVM multi-viewer
1 x USB Power adapter
4 x USB Data cable
1 x Remote control(without 3A battery)
1 x User manual
- 5 Ways Viewing Screen: The 4X1 Quad Multiview Selector support 5 viewing modes. You could see 4 HDMI input sources screen on one monitor by 4 ways, also can only see only one HDMI input source by full screen;
- HDMI Seamless Switch 4 in 1 out: 4 HDMI Input ports, 1 HDMI output port. Support Connect 4 HDMI input device and one HDMI Display device on Switch box, avoid frequently plugging and unplugging on HDMI Display device;
- KVM Control: support hotkey switch,Ctrl + Ctrl to next PC,Ctrl + Shift + 1/2/3/4 to PC1/2/3/4,use Ctrl + Shift + K to enable/ disable hotkey function, the USB 2.0 port could compatible with USB flash driver,printer etc.
- Remote Control and Button Control: 4x1 Quad Multi-Viewer with function buttons and attached IR remote control. Manual button and remote control both support switching input source, selecting full screen mode or quad modes and switch input source's audio;
- Max up to 4K 30hz Resolution: HDMI Multiple display Switch box support 4K 30hz, 1080P 60hz,1080i,720p,567p,576i,480p,480i,bandrate max to 10.2Gbps, Support Color format 24 bit/30 bit/ 36bit;
- Widely Compatible: This HDMI 4X1 Quad Multi-viewer support HDMI 1.4 and HDCP 1.4 and backward compatible. 4 HDMI input port support connecting DVD player, Apple TV, Blu-ray players, PS3/PS4, PS5, game console, fire stick, etc. HDMI output port support connecting various HDMI display device like monitor, HDTV, projector.
