Aluminum Alloy Gaming Laptop Cooler Cooling Pad | 2 Quiet Fans | Support Up to 17.3 Inch Heavy Notebook, Laptop | 5 USB PORTS | 2 Big fans | 380 x 285 x 70 mm | Silver

EXPERT FEATURES

• 4 dual-color line keys (can be digitally programmed as up to 16 provisionable BLF/fast-dial keys)
• 2.4” (320x240) TFT color LCD - 4 programmable context-sensitive soft keys
• Integrated PoE (GRP2612P & GRP2612W only)
• 3-way conference - Electronic Hook Switch (EHS)
• Integrated dual-band WiFi 802.11 a/b/g/n/ac (2.4Ghz & 5Ghz)
• Supports 2 SIP accounts and 4 multi-purpose line keys
• GRP2612W includes built-in dual-band Wi-Fi support
• Swappable faceplate to allow for easy logo customization
• HD audio supporting all major codecs, including wideband codecs G.722 and Opus
• Up to 16 digital BLF Keys
• Enterprise-level protection including secure boot, dual firmware images, and encrypted data storage
• Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated PoE (GRP2612G)

Expert Specifications

Protocols/Standards

• SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPV6

Network Interfaces

• Dual switched auto-sensing 10/100 Mbps Ethernet ports with integrated PoE(*PoE for 2612P only)

Graphic Display

• 2.4 inch (320x240) TFT color LCD

Feature Keys

• 4 line keys with up to 2 SIP accounts
• 4 XML programmable context sensitive softkeys
• 5 navigation/menu keys
• 9 dedicated function keys for: MESSAGE(with LED indicator)
• TRANSFER
• HOLD
• HEADSET
• MUTE
• SEND/REDIAL
• SPEAKERPHONE
• VOL+
• VOL-

Auxiliary Port

• RJ9 headset jack (allowing EHS with Plantronics headsets)

Voice Codecs and Capabilities

• Support for G7.29A/B, G.711µ/a-law, G.726, G.722(wide-band), G723, iLBC, OPUS, in-band and out-of-band DTMF(in audio, RFC2833, SIP INFO)

Telephony Features

• Hold, transfer, forward, 3-way conference, call park, call pickup, shared-call-appearance(SCA)/bridged-line-appearance(BLA), downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 1000 records), XML customization of screen, off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over

HD Audio

• Yes, HD handset and speakerphone with support for wideband audio

Base Stand

• Yes, 2 angle positions available, Wall Mountable (Wall Mount *sold separately)

QoS

• Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

• User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot

Multi-language

• English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean, Japanese, and more

Upgrade/Provisioning

• Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file

Power & Green Energy Efficiency

• Universal power adapter included: - Input:100-240V - Output: +5V, 0.6A - Integrated Power-over-Ethernet(802.3af) - Max power consumption 3W(power adapter) or 3.8W(PoE) (*PoE for 2612P only)

Temperature and Humidity

• Operation: 0°C to 40°C
• Storage: -10°C to 60°C
• Humidity: 10% to 90% Non-condensing

Package Content

• GRP2612W phone
• Handset with cord
• Phone stand
• 5V power adapter (*with GRP2612 only)
• Network cable
• Quick Installation Guide
• GPL license

Physical

• Dimension: 203mm x 193mm x 52.1mm
• Unit weight: 554g
• Package weight: 936g

Compliance

• FCC: Part 15 Class B; Part 15 Subpart C, 15.247; Part 15 Subpart E, 15.407; FCC Part 68 HAC CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; EN 301489-1; EN 301489-17; EN 300328; EN 301893; EN 62311 RCM: AS/NZS CISPR32; AS/NZS 61000.3.2; AS/NZS 61000.3.3; AS/NZS 4268; AS/NZS 62368.1; AS/CA S004 IC: ICES-003; CS-03; RSS-247; RSS-102
