Name: Battery INVO 12V 9 AMP Rechargeable Battery
SKU: INV12-9AH
Availability: InStock

Battery INVO 12V 9 AMP Rechargeable Battery

$ 19

Battery 12V 9AMP Lead Acid Rechargeable

Battery INVO 12V 9 AMP HR Universal Versatile Durable Tab Top Deer Feeder Non-Spillable Sealed Lead Acid Rechargeable Battery

Expert Specifications

Valve Regulated Acid Battery – Voltage: 12V – Ampere Hour 9AH

Capacity range: 1.2-28 (25°C)

Voltage class: 12v

Low self-discharge rate: ≤2%/month (25°C)

Long design life: floating life is 5 years (25°C)

High sealed reaction efficiency≥98%

Acclimation temperature range: -15~50°C

Operation temperature range: -20~50°C

Recommended operation temperature 25°C

12V 9 AMP HR RECHARGEABLE BATTERY – Equip your feeder with reliable energy! Get this durable versatile 12V 9 AMP HR Rechargeable Battery
DURABLE CONSTRUCTION – This rechargeable 12 Volt 9 AMP battery has Non-Spillable Sealed Lead Acid construction
RECHARGEABLE – This versatile battery by American Hunter for game feeders boasts the ability to be recharged
EXPERT BATTERY – The 12V 9 AMP battery also has loads of different uses; This size battery is most commonly used for game feeders, headlights, backup lighting, and household alarms; It will make an ideal addition to any set of outdoor accessories

SKU: INV12-9AH Category: Ups

Compact Size
Line Interactive Design
Fully Digitized Microprocessor Control
Auto Voltage Regulation (AVR)
50/60 Hz Frequency (Auto-Sensing)
Generator Compatible

Cold Start Function (DC Power On)
Advanced Battery Management (ABM Technology)
Advanced Green Mode Function
Lightning and Surge Protection
Short Circuit and Overload Protection
EMI/RFI Noise Filter

Automatic Charging When UPS is Off
Audible Alarm & LED Power Status Display
Smart RS-232/USB Communication Port*
Network/Tel/Modem/Fax Spike Protection*

Model	STE2000
Capacity	2000VA/700W
INPUT
Voltage	110/120 VAC or 220/230/240 VAC
Voltage Range	81-145VAC or 162-290VAC
Frequency Range	60/50 Hz (Auto sensing)
OUTPUT Voltage	110/120 VAC or 220/230/240 VAC
AC Voltage Ragulation (Bat Mode)	±10%
Frequency Range (Bat Mode)	60Hz or 50Hz ± 1Hz
Transfer time	Typical 2-6ms
Waveform (Bat Mode)	Simulated Sinewave
Battery
Battery Type&Number	12V 9Ah*2
Charging ability	4-6 hours recover to 90% capacity
Protection
Full protection	Overload, discharge and overcharge protection
INDICATIONS
LCD Display	AC/Battery Mode, Load/Battery Level, Input /Output Voltage ,Overload, Fault, and low Battery
LED Display	AC Mode	Green lighting	The right green LED lighting& the 2nd to 5th green LEDs gradually lighting indicating load level
	Battery Mode	Yellow flashing	The right green LED flashing& the 2nd to 5th green gradually lighting indicating battery capacity
	Fault	Red lighting
Battery mode	Sounding every 10 seconds
Low battery	Sounding every second
Overload	Sounding every 0.5 seconds
Battery Replacement Alarm	Sounding every 2 seconds
Fault	Continuously sounding
Dimension, DWH(mm)	370135165
Net Weight (kgs)	11.5
Environment
Humidity	0-90% Relative Humidity 0-40 ℃ (Non-condensing)
Noisy Level	Less than 40dB

Specification		Single Phase In & Out
Rated output capacity		6KVA/4.8KW
Rated	Rated voltage	220VAC
AC input	Input voltage range	120-275VAC±5
	Input frequency range	(45-55)±0.5Hz
	bypass voltage	80VACx(1±5%)-285VACx(1±5%)
Battery Input	battery group voltage	192V
	battery method	Internal
	Battery capacity & quantity	12V 7ah X16 PCS
	backup time(half/full)	half load≥10 minutes，full load≥5minutes(standard)
	maximum input current when power on	<150% of rated current
	battery charging time	5hours can charge to 90%(standard)
AC output	Output voltage	220VAC±1%(invert output)
	Output frequency	50±5Hz(when AC input is normal) 50Hz±1% (when ac inout is abnormal )
	wave form	sine wave THD<3%( linear load) sine waveTHD<8%(Nonlinear load)
	output power factor	0.8
	Overload Protection	105-125% ,Transfer to Bypass after 1 Min
	Output current peak coefficient	03:01
	Transfer time between AC and Battery	0ms
Communication and monitoring functions		RS232(can transfer to 485，Dry node，Smart slot(can expand to SNMP,SMS and other monitoring methods)
Tower	N.W(KG)	57
	G.W(KG)	64
	Unit Size(W X H X D)mm	515250620
	Carton Size(W X H X D)mm	660365730

Model	ST3000
Capacity	3000VA/800W
INPUT
Voltage	110/120 VAC or 220/230/240 VAC
Voltage Range	81-145VAC or 162-290VAC
Frequency Range	60/50 Hz (Auto sensing)
OUTPUT Voltage	110/120 VAC or 220/230/240 VAC
AC Voltage Ragulation (Bat Mode)	±10%
Frequency Range (Bat Mode)	60Hz or 50Hz ± 1Hz
Transfer time	Typical 2-6ms
Waveform (Bat Mode)	Simulated Sinewave
Battery
Battery Type&Number	12V 9Ah*2
Charging ability	4-6 hours recover to 90% capacity
Protection
Full protection	Overload, discharge, and overcharge protection
INDICATIONS
LCD Display	AC/Battery Mode, Load/Battery Level, Input / Output Voltage ,Overload ,Fault , and low Battery
LED Display	AC Mode	Green lighting	The right green LED lighting &t he 2nd to 5th green LEDs gradually lighting indicating load level
	Battery Mode	Yellow flashing	The right green LED flashing & the 2nd to 5th green gradually lighting indicating battery capacity
	Fault	Red lighting
Battery mode	Sounding every 10 seconds
Low battery	Sounding every second
Overload	Sounding every 0.5 seconds
Battery Replacement Alarm	Sounding every 2 seconds
Fault	Continuously sounding
Dimension,DWH(mm)	466 x 138 x 166
Net Weight (kgs)	19
Environment
Humidity	0-90% Relative Humidity 0-40 ℃ (Non-condensing)
Noisy Level	Less than 40dB

Input	Rating	1500VA
	Voltage	220/230/240 VAC, 1Ø2Wires
	Voltage Range	162-290VAC
	Frequency	50 or 60 Hz +/-10% (auto sensing)

OuTput	Active Power	600W
	Voltage (backup mode)	220/230/240VAC+/-1%
	Frequency (backup mode)	50 or 60 Hz +/-1%
	Waveform	Simulated Sine Wave
	Transfer time	Typical 2 to 6 ms

Protection	Full Protection	Overload, discharge, and overcharge protection

LED Indicators	AC Mode	Green lighting
	Battery Mode	Green flashing


Alarm	Battery Mode	Sounding every 10 seconds
	Low Battery	Sounding every second
	Overload	Sounding every 0.5 second
	Fault	Continuously sounding

Battery	Battery Type & Number	SLA 12V/7AH x 2
	Typical Recharge Time	4~6 hours (to 90% full capacity)
	Backup time	10~20min depending on load level

Battery INVO 12V 9 AMP Rechargeable Battery

Expert Specifications

Description

Battery 12V 9AMP Lead Acid Rechargeable

Additional information

Related products

Expert Features

Expert Technical Specs

EXPERT DESCRIPTION

Technical Specs

GENERAL

INPUT

OUTPUT

BATTERY

ALARM & INDICATORS

Rear Panel

NCTS Smart UPS On-Line SRV 6000VA 4.8KW / 4.8KW battery group voltage 192V

Smart UPS On-Line SRV 6000VA / 6KVA ; Specifications

Specification

Rated output capacity

Rated

Rated voltage

AC input

Input voltage range

Input

frequency range

bypass voltage

Battery Input

battery group voltage

battery method

Battery capacity & quantity

backup time(half/full)

maximum input current when power on

battery

charging

time

AC output

Output

voltage

Output frequency

wave form

output power factor

Overload Protection

Output current peak coefficient

Transfer time between AC and Battery

Communication and monitoring functions

Tower

N.W(KG)

G.W(KG)

Unit Size(W X H X D)mm

Carton Size(W X H X D)mm

EXPERT FEATURES

EXPERT SPEC

PCE UPS SYSTEM M8-1500 1500VA 600W
