Additional information
| VEIKK , A50 , DRAWING , TABLET , 10 | {attribute:VEIKK , A50 , DRAWING , TABLET , 10 |
|---|
Back to products
Next product
DisplayPort to DisplayPort 1.8M Cable, DP to DP Male to Male , Supports 4K@60Hz, 2K@144Hz Compatible for Lenovo, Dell, HP, ASUS and More
Original price was: $ 9.$ 5Current price is: $ 5.
Biostar IH61MF-Q5 Motherboard (H61, S1155, mATX, DDR3, Intel)
$ 81
Additional information
Related products
MSI H510M PLUS V3 MOTHERBOARD , Supports up to10th Gen Intel ONLY, Micro-ATX 64GB 2933MHz DDR4 memory , Core Boost Technology, Memory Boost & Audio Boost , Armored PCIe Slot
MSI H510M PLUS V3 Micro ATX MOTHERBOARD 10th Gen ONLY
EXPERT FEATURES
- Supports up to 10th Gen Intel Core ONLY , Pentium® Gold and Celeron® memory using LGA 1200 socket
- Supports DDR4 memory, maximum speed up to 2933(Max) MHz
- Core Boost Technology: with premium chassis and digital power design that supports multiple cores and delivers better performance.
- Memory Boost: advanced technology that delivers clean signals for ultimate performance and stability.
- Audio Boost: Pamper your ears with studio-grade sound
- Armored PCIe Slot: Protect VGA cards from curvature and electronic interference for better performance, stability and power.
MSI H510M PLUS
MSI H510M PLUS helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.EZ Debug LED
Easiest way to troubleshoot.Memory Boost
Advanced technology to deliver pure data signals for the best performance, stability and compatibility.Core Boost
With premium layout and fully digital power design to support more cores and provide better performance.Expert Specifications
| CHIPSET | INTEL H470 |
|---|---|
| CPU SUPPORT | Supports 10th Gen Intel Core and Pentium Gold/Celeron processors for LGA 1200 Socket |
| MEMORY | 2x DDR4, Maximum Memory Capacity 64GB Memory Support 2933/ 2666/ 2400/ 2133 MHz Supports 1R 2133/ 2666/ 2933 MHz for Intel® Core™ i9/ Core™ i7 CPU Supports 1R 2133/ 2666 MHz for Intel® Core™ i5/ Core™ i3/ Pentium® Gold and Celeron® CPU Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
| ONBOARD GRAPHICS | 1x HDMI™ Support HDMI™ 1.4, maximum resolution of 4K 30Hz* 1x D-Sub Support VGA, maximum resolution of 2048×1536 50Hz, 1920×1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| EXPANSION SLOT | 1x PCI-E x16 slot (Qty) 1x PCI-E x1 slot (Qty) PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| STORAGE | 1x M.2 (Qty) M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G (Qty) |
| USB | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
| LAN | Realtek® 8111H Gigabit LAN |
| AUDIO | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| INTERNAL I/O | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS |
|
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB DIMENSION (W × L) | mATX 202mmx236mm |
Esonic B250DA1 M.2 DDR4 Desktop Micro-ATX Motherboard LGA 1151 , Supports Intel 6th 7th 8th 9th Gen Core i7 i5 i3 , Dual Memory Channel , Integrated Audio Chip , USB3.0 SATA 3.0 LAN
Esonic B250DA1 DDR4 Motherboard Micro ATX
Expert Specs
- Maximum Ram Capacity : 64 GB
- Application : Desktop
- Form Factor : Micro-ATX
- Memory Type : DDR4
- Graphics Card Type : Non-Integrated
- Ports : SATA, VGA, PCI-Express X16, USB 2.0, M.2, USB 3.0, Usb3.1
- Chipset : Intel B250
- Socket Type : LGA 1151
- Memory Bank : 2 DDR4 DIMM
- CPU Type : Intel
- Memory channel : Double
- Private Mold : Yes
- Chipset Manufacturer : Intel
- Hard Drive Interface : SATA
- FSB / HT : 2133/2400MHz
- CPU : 6th/7th/8th/9th Gen Core i7/i5/i3/ Pentium/Celeron
- Memory : 2 * DDR4 2133/2400 DIMM, Max. 64GB
- USB : 2*USB2.0/4* USB 3.0
- LAN : 100M 1000M optional
- Size : 20cm X 17cm
- Storage : 4 * SATA 3.0 port(s), 1 * M2_SSD(2280) slot
- Brand Name : Esonic motherboard
- Condition : 100% Tested Working
B250DA1
Esonic B250DA1 DDR4 DDR3 Motherboard Micro ATX
Esonic B250DA1 M.2 DDR4 DDR3 Desktop Micro-ATX Motherboard LGA 1151 , Supports Intel 6th 7th 8th 9th Gen Core i7 i5 i3 , Dual Memory Channel , Integrated Audio Chip , USB3.0 SATA 3.0 LAN
ASROCK H510 Pro BTC+ MINING BOARD
Crypto Mining
This motherboard is specifically designed for mining, the revolutionary digital crypto-currency that may be used anywhere in the world. The abundant onboard PCIe slots guarantee fast Crypto mining, while the additional power connectors provide advanced system stability while mining.
M.2 For SSD
M.2 socket supports 2260/2280/22110 SATA3 mode M.2 SSD for up to 6Gb/s.
Smart PCIe State Detection
This motherboard has included a smart way to show the status of every graphics card. While the system is booting, the Power-On, Self-Test (POST) screen will show the status of the graphics cards that were installed on the motherboard.
USB Type PCIe x1 Mining Ports
Onboard USB Type PCIe x1 Mining Ports for Setting Up Even More Graphics Cards.
PCI-E STEEL SLOTS
The advanced PCI-E Steel Slots packed with solid cover that prevent any signal interference with graphics cards. It also ensures the heavy graphics cards to be well-installed in the PCI-E slots safely.
Riser Kit Free
Install graphics cards directly on the motherboard without using riser kits to ensure ultimate stability.
*Graphics cards not include in the motherboard package.
Intel® LAN
Intel® LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!
Sapphire Black PCB
Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.
Power On / Reset Button
Power On & Off system with onboard button is a must for open frame mining.
Digi Power
Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
MSI MOTHERBOARD B760M BOMBER WIFI DDR5 (911-7D90-026)
MSI MOTHERBOARD B760M BOMBER WIFI DDR5
MSI B760M Bomber WiFi Motherboard, Micro-ATX
Supports Intel 12th & 13th Gen Core Processors, LGA 1700 - DDR5 Memory Boost 6400MHz/MAX, PCIe 4.0 x16 Slot, M.2 Gen4 Slot
-
Supports 12th/13th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
-
Supports DDR5 Memory, Dual Channel DDR5-6400+MHz (OC)
-
Core Boost : With premium layout and digital power design to support more cores and provide better performance
-
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
-
Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
-
2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
-
AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
-
Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength
B760M BOMBER WIFI SPECS
| CHIPSET | INTEL B760 |
|---|---|
| CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700 |
| MEMORY | 2x DDR5, Maximum Memory Capacity 96GB Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) Max. overclocking frequency: • 1DPC 1R Max speed up to 6400+ MHz • 1DPC 2R Max speed up to 5600+ MHzSupports Intel® XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| ONBOARD GRAPHICS | 1x HDMI™ Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x D-Sub Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| SLOT | 1x PCI-E x16 slot (Qty) 1x PCI-E x1 slot (Qty) PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 4.0 supports up to (From Chipset) |
| STORAGE | 2x M.2 (Qty) M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G (Qty) |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
| LAN | Realtek® RTL8125B 2.5Gbps LAN |
| WIRELESS LAN & BLUETOOTH | Intel® Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth® 5.3, FIPS, FISMA * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. |
| AUDIO | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| INTERNAL IO | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS |
|
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB INFO | mATX 220mmx243.84mm |
| BOX CONTENT |  |
ASUS Prime Z790-V AX WIFI Intel Z790 LGA 1700 ATX DDR5 – 90MB1G40-MVAAY0
ASUS PRIME Z790-V WIFI
CPU
Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset
Intel® Z790 Chipset
Memory
4 x DIMM slots, Max. 192GB, DDR5 7200 (OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory
configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/.
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Graphics
1 x HDMITM port**
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots
Intel® 13th & 12th Gen Processors*
1 x PCIe 5.0 x16 slot
Intel® Z790 Chipset
3 x PCIe 4.0 x16 slots (support x4 mode)
1 x PCIe 3.0 x1 slot
* Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
Storage
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel® 13th & 12th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
Intel® Z790 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.
Ethernet
1 x Realtek 1Gb Ethernet
Wireless & Bluetooth
Wi-Fi 5
Wi-Fi 5 (802.11 a/b/g/n/ac)
Supports 2.4/5GHz frequency band Bluetooth v5.0*
* The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB
Rear USB (Total 8 ports)
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
1 x USB 3.2 Gen 2 port (1 x Type-A)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 9 ports)
1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
* USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.
* USB_E5 port, USB_E6 port, USB_E7 port and USB_E8 port share the bandwidth.
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
1 x USB 3.2 Gen 2 port (1 x Type-A)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x HDMITM port
1 x Wi-Fi Module
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
3 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
Storage related
3 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
2 x USB 3.2 Gen 1 headers support4 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 20-5pin System Panel header
1 x Thunderbolt™ (USB4®) Header
Special Features
ASUS 5X PROTECTION III
- DIGI+ VRM (- Digital power design with DrMOS)
- LANGuard
- Overvoltage Protection
- SafeSlot Core+
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-DIMM
- Q-Slot
- Q-LED Core
ASUS Thermal Solution
- VRM heatsink design
ASUS EZ DIY
- ProCool
Aura Sync
- Aura RGB header
- Addressable Gen 2 headers
Software Features
ASUS Exclusive Software
Armoury Crate
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
-Two-Way AI Noise Cancelation
AI Suite 3
-TurboV EVO
-PC Cleaner
-DIGI+ VRM
ASUS CPU-Z
MyASUS
Norton 360 Deluxe (60 Days Free Trial)
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
POWER MAX ARGB 24PIN White Power Extension Cable Kit Addressable 5V 3pin Connectors for Motherboard , Four Sides Chunky Silicon Rainbow Bridge 5V ARGB PC PSU Cables, White
ARGB 24PIN Power Extension Cable Motherboard
POWERMAX-24PIN
ARGB 24PIN Power Extension Cable Motherboard
ARGB 24PIN White Power Extension Cable Kit Addressable 5V 3pin Connectors for Motherboard , Chunky Silicon Rainbow Bridge 5V ARGB PC PSU Cables, White
Expert Features
- Connector Type : 5v 3pin Female and Male
- Cable Type : 24pin extension cable with ARGB effects
- Compatible Devices : Gaming computer, desktop
- Special Feature : Double side with ARGB effects, addressable
- 【All-white Design】: White extension cable, weave in white, suitable for white graphics card and motherboard, better customize your white chassis and keep the color consistent.
- 【Update Version】: RGB PC cables make of TPE/silicone material, can easy to bend and routing; Silver-plated wire core maintains stable current transfer.
- 【LIGHTED ON FOUR SIDES】: Double LED light sources increase the brightness of RGB, thus makes the RGB brighter, even under the day or the bright light environment, the brightness is still very bright, Stunning ARGB Lighting Effect. Let you have a more
- refreshing feeling in the process of gaming or work.
- 【24 Pin PSU Extension Cable Kit】24Pin extension cable for motherboard adopt thicker copper core, suitable for high voltage, suitable for all power supplies on the market.
- 【5V ARGB SYNC】: Support ASUS, MSI, Gigabyte and ASRock motherboard addressable 5V3pin ARGB, programmable and customizable light effects.
POWERMAX-24PIN
ARGB 24PIN Power Extension Cable Motherboard
ARGB 24PIN White Power Extension Cable Kit Addressable 5V 3pin Connectors for Motherboard , Chunky Silicon Rainbow Bridge 5V ARGB PC PSU Cables, White
GIGABYTE B650M DS3H (AM5/ LGA 1718/ AMD/ B650/ Micro ATX/ DDR5/ PCIe 4.0 M.2/ PCIe 4.0/ USB 3.2 Gen2X2 Type-C/ 2.5GbE LAN/Motherboard)
GIGABYTE B650M DS3H DDR5 Motherboard
EXPERT FEATURES
- AMD AM5 Socket: Supports AMD Ryzen 7000 Series Processors
- DDR5 Compatible: 4*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
- Sturdy Power Design: Direct 6+2+1 Phases Digital VRM Solution
- Comprehensive Thermal Design: Advanced Thermal Design, M.2 Thermal Guard
- Next Gen Connectivity: PCIe 5.0, NVMe PCIe 4.0 x4 M.2, SuperSpeed USB 3.2 Gen 2x2 Type-C
- Fast Networking: 2.5GbE LAN
- Fine Tuning Features: RGB FUSION 2.0, Supports Addressable LED & RGB LED Strips, Smart Fan 6, Q-Flash Plus Update BIOS without installing, CPU, Memory, and GPU"
EXPERT SPECS
| Brand | GIGABYTE |
|---|---|
| Model | B650M DS3H (rev. 1.0) |
| Part Number | B650M DS3H (rev. 1.0) |
| CPU Socket Type | AM5 |
|---|---|
| CPU Type | AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors |
| Chipset | AMD B650 |
|---|
| Number of Memory Slots | 4x288pin (DDR5) |
|---|---|
| Memory Standard | Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / MT/s memory modules |
| Maximum Memory Supported | 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
| Channel Supported | Dual channel memory architecture |
| ECC Supported | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Buffer Supported | Un-buffered |
| Memory Feature | Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information. |
| PCI Express 4.0 x16 | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) |
| SATA 6Gb/s | 4 x SATA 6Gb/s |
|---|---|
| M.2 | 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) |
| SATA RAID |
|
| Audio Chipset | Realtek® Audio CODEC |
|---|---|
| Audio Channels |
|
| Max LAN Speed | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
|---|
| Back I/O Ports | 4 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 2 x DisplayPorts 1 x HDMI port 1 x USB 3.2 Gen 2 Type-A port (red) 1 x USB Type-C® port, with USB 3.2 Gen 2 support 1 x Q-Flash Plus button 1 x RJ-45 port 2 x USB 3.2 Gen 1 ports 3 x audio jacks |
|---|---|
| PS/2 | 1 x PS/2 keyboard/mouse port |
| Other Connectors |
|
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 24.4cm x 24.4cm |
| Windows 11 | Support for Windows 11 64-bit Support for Windows 10 64-bit |
|---|
MSI PRO Z790-P II DDR5 Motherboard | Support Intel® Core™ 14th/ 13th/ 12th Gen | Dual Channel DDR5 7200+MHz (OC) | Extended Heatsink | 2.5G LAN | Intel Turbo USB 3.2 Gen 2
MSI PRO Z790-P II DDR5 Motherboard
EXPERT FEATURES
- Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
- Supports DDR5 Memory, Dual Channel DDR5 7200+MHz (OC)
- Enhanced Power Design: 14+1+1 DRPS with 55A DrMOS, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
- Intel Turbo USB 3.2 Gen 2: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds
- 2.5G LAN: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
EXPERT SPECS
CHIPSET |
INTEL Z790 |
|---|---|
CPU |
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700 |
MEMORY |
4x DDR5, Maximum Memory Capacity 256GB
Memory Support 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7200+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5600+ MHz
|
ONBOARD GRAPHICS |
|
SLOT |
|
STORAGE |
|
RAID |
|
USB |
|
LAN |
Intel® 2.5Gbps LAN |
| AUDIO |
|
| INTERNAL IO |
|
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS |
|
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB INFO | ATX 243.84mmx304.8mm |
| BOX CONTENT |  |
