GAMDIAS CHIONE P5-240 WH AIO ARGB Liquid Cooler  – 3.4” IPS LCD, 240mm Radiator, ARGB PWM Fans, Rotatable Display, Upgraded Cooling System, Universal Compatibility, Hidden Cable Routing, Motherboard Sync | WHITE

Expert Features

• Immersive 3.4″ IPS LCD Display – Monitor real-time system performance, display custom images, or add animated GIFs for a truly personalized look.
• Rotatable Magnetic Display – No awkward angles! The LCD screen can be repositioned by simply pulling and reattaching, or fine-tuned using ZEUS CAST software for perfect orientation.
•  Powerful 2700 RPM Pump – The 12-slot, 10-pole motor ensures smooth fluid circulation and consistent cooling, all while keeping noise levels impressively low.
• Advanced Dual ARGB PWM Fans – Two 120mm hydraulic bearing fans provide an airflow of 81.81 CFM, delivering high static pressure (3.15 mmH2O) while maintaining quiet operation.
• Upgraded Coldplate with Microflow Technology – Features 0.12mm microchannels that optimize heat transfer, effectively targeting CPU hotspots for faster and more efficient cooling.
• High-Efficiency 240mm Radiator – With dense aluminum fins, this radiator maximizes heat dissipation, keeping temperatures low even under heavy workloads.
• Smart Fan & Pump Control – The PWM fans adjust speeds from 400 to 2200 RPM, ensuring optimal cooling when needed and whisper-quiet operation when idle.
• Dynamic ARGB Lighting Effects – Choose from 30 pre-set effects or sync with your motherboard’s 5V 3-pin ARGB header for a fully customizable RGB experience.
• Hidden Cable Management – Say goodbye to messy cables! Integrated routing keeps everything clean and organized, enhancing both aesthetics and airflow.
•  Universal Mounting Compatibility – Supports Intel LGA 1851, 1700, 1200 and AMD AM5, AM4, AM3+, ensuring seamless installation across modern platforms.

Expert Specs:

🖥 LCD Display

• Screen Size: 3.4″ IPS LCD
• Resolution: 480 × 480 pixels
• Customization: Upload GIFs, images, and system stats
• Rotation: Magnetic, software-controlled

💦 Liquid Cooling System

• Pump Speed: Up to 2700 RPM
• Motor Type: 12-slot, 10-pole motor for stable and efficient flow
• Coldplate Design: 0.12mm microchannels for rapid heat dissipation
• Radiator Material: High-density aluminum fins for improved cooling efficiency
• Radiator Dimensions: 276 × 120 × 27 mm

🌪 Fan Performance

• Quantity: 2 × 120mm hydraulic bearing PWM fans
• Dimensions: 120 × 120 × 25 mm
• Speed: 400 – 2200 RPM (±10%)
• Noise Level: 11 – 34.91 dBA
• Airflow: 81.81 CFM
• Static Pressure: 3.15 mmH2O
• Rated Voltage: 12V (Fan), 5V (LEDs)
• Connector: PWM & 5V ARGB Sync

⚙ Compatibility & Installation

• Supported Sockets:
  1. Intel: LGA 2066, 2011-v3, 2011, 1851, 1700, 1200, 1151, 1150, 1155, 1156
  2. AMD: AM5, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
• RGB Sync: Supports 5V 3-pin addressable RGB headers
• Hidden Cable Routing: Integrated system for a tidier, cleaner setup
• Mounting Kit: Included for easy installation
