MONTECH HS01 PRO White ATX Mid-Tower Gaming Case, 5×120mm GF120 V2 ARGB Fans, Reversible Glass, Mesh Front, 420mm GPU & 360mm AIO Support

105 $

Expert Features

  • Five Pre-Installed ARGB Fans: The PRO edition arrives with five GF120 V2 ARGB 120mm fans already installed: three bottom-mounted fans and two rear-mounted fans, delivering an attractive starting cooling configuration without extra fan purchases.
  • Elegant White High-Airflow Design: Combines a crisp white chassis, a ventilated mesh front panel and a tempered-glass side panel to showcase a clean, airflow-focused gaming build.
  • Reversible Glass-Panel Layout: The case can be configured with its tempered-glass viewing panel on either the left or right side to suit your desk and setup.
  • Chimney-Style Cooling: The case is engineered around upward airflow, drawing cooler air from the bottom and allowing heated air to escape through the top, assisted by the dual rear fans.
  • Spacious, Sunken Internal Layout: The recessed internal arrangement helps present components neatly and uses space efficiently for powerful gaming or workstation configurations.
  • ARGB Lighting Control: The five included GF120 V2 ARGB fans support motherboard ARGB synchronization; MONTECH also advertises 29 built-in lighting modes.
  • Broad Motherboard Compatibility: Supports ATX, Micro-ATX and Mini-ITX motherboards, including compatible back-connect layouts such as MSI Project Zero, ASUS BTF and Gigabyte Project STEALTH.
  • Large Graphics Card Clearance: Provides up to 420mm GPU clearance for accommodating long high-performance graphics cards.
  • Flexible GPU Presentation: The reversible platform uses rotatable PCIe expansion slots, allowing horizontal or vertical GPU presentation subject to component compatibility.
  • High-Capacity Cooling Expansion: Fan mounting positions support up to three 120mm fans on top, three 120mm or two 140mm fans at the front, three 120mm at the bottom and two 120mm at the rear.
  • 360mm Top Radiator Support: Supports 120mm, 240mm or 360mm top radiators and 120mm or 240mm bottom radiators; top radiator width must not exceed 123mm.
  • Generous Hardware Clearance: Accommodates CPU air coolers up to 175mm tall and ATX power supplies up to 200mm long; SFX power supplies are also supported.
  • Practical Front I/O: Includes two USB 3.0 Type-A ports, one USB Type-C port, headphone and microphone connections, a power button and a dedicated LED button.
  • Flexible Storage and Dust Control: Offers installation capacity for up to two 3.5-inch HDDs and four 2.5-inch SSDs, plus a bottom dust filter for easier maintenance.

Expert Specs

Brand MONTECH
Model HS01 PRO
Color White
Case Type ATX Mid-Tower
Dimensions (L × W × H) 480 × 240 × 480mm
Carton Dimensions 563 × 323 × 573mm
Motherboard Support ATX / Micro-ATX / Mini-ITX
Back-Connect Motherboards Supported
Side Panel Reversible Tempered Glass
Front Panel Ventilated Mesh
Included Fans 5 × GF120 V2 ARGB, 120mm
Included Bottom Fans 3 × 120mm ARGB
Included Rear Fans 2 × 120mm ARGB
Top Fan Support 3 × 120mm
Front Fan Support 3 × 120mm or 2 × 140mm
Bottom Fan Support 3 × 120mm
Rear Fan Support 2 × 120mm
Top Radiator Support 120 / 240 / 360mm (max. 123mm radiator width)
Bottom Radiator Support 120 / 240mm
Maximum GPU Length 420mm
Maximum CPU Cooler Height 175mm
Maximum PSU Length 200mm
Power Supply Support ATX / SFX (not included)
PCIe Expansion Slots 7
3.5-inch Drive Capacity Up to 2
2.5-inch Drive Capacity Up to 4
Dust Filter Bottom
ARGB Control Motherboard ARGB Sync / 29 Lighting Modes
Front I/O 2 × USB 3.0 Type-A / 1 × USB Type-C / Mic / Headphone / Power / LED Button

Features & Compatibility

HS01-PRO-WHITE

MONTECH HS01 PRO AIRFLOW ATX MID TOWER CASE/5*120MM ARGB PWM FAN/TEMPERED GLASS-WHITE

MONTECH HS01 PRO White ATX Mid-Tower Gaming Case, 5×120mm GF120 V2 ARGB Fans, Reversible Glass, Mesh Front, 420mm GPU & 360mm AIO Support
