OTN-9175S
ONTEN 3 IN 1 USB-C TO HDMI *2 ADAPTER WITH PD 3.0 100W
ONTEN OTN-9175S 3-in-1 USB-C to Dual HDMI Adapter, 4K@60Hz + 2K@60Hz, PD 3.0 100W Charging, SST or Extended Display Support, Compact Multi-Monitor Hub for USB-C Devices and Laptops
Expert Features
- 3-in-1 USB-C Expansion : Connect one USB-C device to two HDMI displays while keeping a dedicated USB-C PD charging port available.
- Dual HDMI Video Output : Two HDMI ports let you build a dual-display setup from a single compatible USB-C connection.
- 4K@60Hz Primary HDMI : One HDMI output supports video resolution up to 4K at 60Hz for sharp, fluid high-resolution output.
- 2K@60Hz Secondary HDMI : The second HDMI output supports up to 2K at 60Hz for an additional display.
- PD 3.0 100W Charging : Dedicated USB-C Power Delivery input supports PD 3.0 up to 100W.
- SST / Extended Display Support : Designed to support SST or Extended Display operation as specified for the OTN-9175S.
- Single-Cable USB-C Host Connection : The integrated USB-C cable keeps the adapter compact and ready for desk, office, or multi-monitor setups.
- Compact Multi-Display Adapter : Combines dual HDMI connectivity and USB-C PD charging in one streamlined ONTEN hub.
Expert Specs
| Specification | Details |
|---|---|
| Brand | ONTEN |
| Model | OTN-9175S |
| Product Type | 3-in-1 USB-C to Dual HDMI Adapter with PD |
| Host / Uplink Connection | USB-C |
| HDMI Outputs | 2 × HDMI |
| HDMI Output 1 | Up to 4K@60Hz |
| HDMI Output 2 | Up to 2K@60Hz |
| Power Input | USB-C PD |
| Power Delivery Standard | PD 3.0 |
| Maximum PD Power | 100W |
| Display Support | SST or Extended Display |
| Main Function | Dual HDMI video output plus USB-C Power Delivery charging |
