KSTAR UA150 1500VA Line Interactive UPS With Double Boost Single Buck AVR, 900W Output, Simulated Sinewave Backup, Cold Start, Fast Charging, Network Protection, Four Output Sockets, 12V / 9Ah × 2 Batteries

69 $

Expert Features

  • Line Interactive UPS Design : Provides intelligent power protection with rapid response to unstable utility conditions.
  • 1500VA / 900W Power Capacity : Engineered for high-load desktops, workstations, networking equipment, POS systems, and office infrastructure.
  • Double Boost & Single Buck AVR : Actively stabilizes voltage in harsh power environments without excessive battery switching.
  • Simulated Sinewave Output : Ensures reliable backup power for sensitive electronic devices during outages.
  • Cold Start Function : Allows the UPS to start directly from battery power when AC input is unavailable.
  • Automatic Restart Function : System restarts automatically when utility power is restored.
  • Fast Charging Capability : Recharges batteries to 90% capacity within 6–8 hours.
  • Auto Charging In Off Mode : Continues charging batteries even when the UPS is switched off but connected to mains power.
  • Built-In Self-Diagnostic Function : Continuously monitors internal status for dependable long-term operation.
  • Modem / LAN Surge Protection : Protects connected network and internet lines from electrical surges.
  • Generator Compatible : Designed to work with generator input where supported.
  • LED Indicator Panel  : Displays AC mode, battery mode, load level, and battery level.
  • Compact And Efficient Chassis : Optimized size reduces floor space usage and shipping cost.
  • Low Noise Operation : Operates below 40dB, suitable for office and professional environments.

Expert Specs

Specification Details
Brand KSTAR
Series UA Series
Model UA150
UPS Type Line Interactive
Phase Single Phase (1:1)
Power Factor 0.6
Capacity 1500VA / 900W
Nominal Input Voltage 110/120 Vac or 220/230/240 Vac
Input Voltage Range 81–145 Vac / 162–290 Vac
Input Frequency Range 50/60 Hz (±10%)
Output Voltage (Battery Mode) Simulated Sinewave ±10%
Output Frequency (Battery Mode) 50 Hz or 60 Hz ±1 Hz
Transfer Time Typical 2–6 ms, Max 10 ms
Battery Type 12V / 9Ah × 2
Typical Recharge Time 6–8 Hours (To 90% Capacity)
Protection Overload And Overcharge Protection
Indicators (LED Version) AC Mode, Battery Mode, Load Level, Battery Level
Alarm – Battery Mode Beep Every 10 Seconds
Alarm – Battery Low Beep Every Second
Alarm – Overload Beep Every 0.5 Second
Alarm – Battery Replacement Beep Every 2 Seconds
Alarm – Fault Continuous Beep
Management Interface NONE
Supported OS (Optional) NONE
Operating Temperature 0°C – 40°C
Humidity Range 0–95% (Non-Condensing)
Noise Level <40dB (1 Meter)
Dimensions (W×D×H) 158 × 380 × 198 mm
Net Weight 11.1 kg
Safety Standards IEC/EN62040-1; IEC/EN60950-1
EMC Standards IEC/EN62040-2; IEC61000-4-2/3/4/5/6/8

Features & Compatibility

KSTAR-UA150

KSTAR UA150 1500VA Line Interactive UPS With Double Boost Single Buck AVR, 900W Output, Simulated Sinewave Backup, Cold Start, Fast Charging, Network Protection, Four Output Sockets, 12V / 9Ah × 2 Batteries





1500VA / 900W Power Output
Line Interactive UPS
Double Boost Single Buck AVR
Simulated Sinewave Output
Cold Start Function
Fast Battery Charging
Auto Restart On Power Recovery
Dual Battery Design
Modem And LAN Protection
Low Noise Operation
