CENTURYII-1050W
MONTECH CENTURY II 1050W Fully Modular Gaming PSU, ATX 3.1, PCIe 5.1, 80 PLUS Gold, Cybenetics Platinum, Native 12V-2×6, 135mm FDB Fan & Smart Zero Mode | Chrome & Graphite
MONTECH CENTURY II 1050W Fully Modular Gaming PSU, ATX 3.1, PCIe 5.1, 80 PLUS Gold, Cybenetics Platinum, Native 12V-2×6, 135mm FDB Fan & Smart Zero Mode | Chrome & Graphite
144 $
MONTECH CENTURY II 1050W — Expert Features
- 1050W Continuous Power : Delivers up to 1050W, including the full rated output available through its +12V rail.
- 80 PLUS Gold Efficiency : Certified for efficient power conversion, helping reduce unnecessary energy loss and heat.
- Cybenetics Platinum Efficiency : Separately certified under Cybenetics’ efficiency-testing methodology.
- ATX 3.1 Compatibility : Supports modern power-delivery requirements for high-performance processors and graphics cards.
- PCIe 5.1 Ready : Offers modern graphics-card power connectivity for compatible gaming systems.
- Native 12V-2×6 Connector : Includes a dedicated 16-pin GPU power cable for compatible next-generation graphics cards.
- Fully Modular Design : Use only the cables your build needs for easier installation and more organized cable routing.
- 100% Japanese Capacitors : Uses Japanese capacitors in its premium power-delivery architecture.
- Advanced Power Conversion : Combines Active PFC, Half-Bridge LLC and DC-to-DC technologies.
- 135mm FDB Cooling Fan : Uses a large fluid dynamic bearing fan for thermal management.
- Smart Zero Fan Technology : Stops the cooling fan during suitable low-load conditions to reduce noise.
- Compact 140mm Depth : Its relatively short ATX enclosure helps installation in compatible gaming cases.
- Flat Modular Cables : Flexible, low-profile cabling simplifies routing inside a gaming PC.
- Six Electrical Protections : Includes OPP, OVP, UVP, SCP, OCP and OTP safeguards.
- Full-Range AC Input : Supports 100–240V AC input for different electrical markets.
- 1-Year Manufacturer Warranty : Manufacturer-listed 1-year coverage.
CENTURY II 1050W — Expert Specs
General Specifications
| Specification | Details |
|---|---|
| Brand | MONTECH |
| Series | CENTURY II |
| Model | CENTURY II 1050W |
| Product Type | Fully Modular ATX Power Supply |
| Rated Power | 1050W |
| Design | Metallic-Silver Top / Black Body |
| Form Factor | ATX |
| Dimensions | 140 × 150 × 86mm |
| ATX Standard | ATX 3.1 |
| PCIe Standard | PCIe 5.1 |
| GPU Power Connector | Native 12V-2×6, 16-Pin |
| 80 PLUS Rating | Gold |
| Cybenetics Efficiency | Platinum |
| Cable Management | Fully Modular |
| Included Cable Design | Flat |
| Cooling Fan | 135mm |
| Fan Bearing | Fluid Dynamic Bearing |
| Cooling Technology | Smart Zero Fan |
| Capacitors | 100% Japanese |
| Power Architecture | Active PFC / Half-Bridge LLC / DC-to-DC |
| Operating Temperature | 0–40°C |
| Electrical Protections | OPP / OVP / UVP / SCP / OCP / OTP |
| Manufacturer Warranty | 1 Year, subject to manufacturer conditions |
| EAN | 4710562743371 |
Electrical Specifications
| Electrical Parameter | Specification |
|---|---|
| AC Input Voltage | 100–240V |
| AC Frequency | 50–60Hz |
| Rated Input Current | 15–10A |
| +3.3V Output | 20A |
| +5V Output | 20A |
| +12V Output | 87.5A |
| -12V Output | 0.3A |
| +5VSB Output | 3A |
| Combined +3.3V / +5V Output | 100W |
| Maximum +12V Output | 1050W |
| Maximum -12V Output | 3.6W |
| Maximum +5VSB Output | 15W |
| Total Rated Output | 1050W |
Modular Cable Configuration
| Cable Type | Included Cables | Total Connectors |
|---|---|---|
| Motherboard, 20+4 Pin | 1 | 1 |
| CPU EPS, 4+4 Pin | 2 | 2 |
| PCIe, 6+2 Pin | 3 | 6 |
| Native 12V-2×6, 16 Pin | 1 | 1 |
| SATA | 3 | 12 |
| Peripheral Molex | 1 | 4 |
