MONTECH-TEN-BLK
MONTECH TEN M-ATX MIDTOWER CASE/FULL MESH/1*92MM FAN-BLK
MONTECH TEN Black 22.7L Modular Micro-ATX Gaming Case, 3 Build Modes, Mesh Panels, 425mm GPU Clearance, 360mm Radiator Support, 92mm Rear Fan & 20Gbps USB-C
MONTECH TEN Black 22.7L Modular Micro-ATX Gaming Case, 3 Build Modes, Mesh Panels, 425mm GPU Clearance, 360mm Radiator Support, 92mm Rear Fan & 20Gbps USB-C
68 $
TEN Black — Expert Features
Three adaptable configurations, a 22.7L main frame, fully ventilated mesh construction, and 20Gbps USB-C for a compact performance-focused gaming PC. Actual radiator and component compatibility varies by mode.
- Triple-Mode Modular Architecture: Switch between M1, M2 and I3 configurations to accommodate different motherboard sizes, cooling systems and hardware arrangements.
- 22.7L Compact Frame: The 22.7L main frame maximizes space efficiency. The fully assembled enclosure occupies approximately 29.3L including protruding elements.
- Advanced Mesh Construction: Extensive perforated panels encourage ventilation while giving the chassis a sophisticated minimalist appearance.
- Chimney-Effect Cooling: Ventilation architecture encourages cool air to enter from below and heated air to escape upward.
- Micro-ATX and Mini-ITX Ready: M1 and M2 accommodate either motherboard format; I3 is dedicated to Mini-ITX.
- 425mm Maximum GPU Clearance: M1 supports compatible horizontally installed graphics cards measuring up to 425mm; other modes have different limits.
- 360mm Radiator Compatibility: Side, top or bottom liquid-cooling possibilities depend on the configuration and GPU orientation.
- Pre-Installed 92mm Rear Fan: One factory-installed rear fan provides an initial cooling component.
- Adjustable Power-Supply Placement: M1 and M2 accommodate ATX, SFX-L and SFX power supplies; I3 supports SFX and SFX-L.
- Flexible GPU Orientation: Different configurations accommodate horizontal or vertical GPU installation, subject to component clearance and suitable mounting accessories.
- Versatile Storage Support: M1/M2 support up to two 3.5-inch drives or four 2.5-inch SSDs; I3 supports up to three 2.5-inch SSDs.
- 20Gbps USB-C Connectivity: Front USB Type-C joins two USB 3.0 ports and a combined headset connection.
- Bottom Dust Filtration: The bottom filter helps protect the lower ventilation area.
- 10th Anniversary Accessories: Includes MONTECH commemorative items and eight specialized Velcro cable-management straps.
TEN Black — Expert Specs
Chassis Specifications
| Specification | Details |
|---|---|
| Brand | MONTECH |
| Model | TEN |
| Color | Black |
| Case Type | Modular Compact Gaming Case |
| Configurations | M1 / M2 / I3 |
| Main Frame Dimensions | 420 × 185 × 293mm |
| Main Frame Volume | 22.7L |
| External Dimensions Excluding Protrusions | 442 × 196.5 × 326.05mm |
| External Volume Excluding Protrusions | 28.3L |
| External Dimensions Including Protrusions | 456 × 196.5 × 327.65mm |
| External Volume Including Protrusions | 29.3L |
| Carton Dimensions | 505 × 260 × 395mm |
| Exterior | Ventilated Modular Mesh |
| Pre-Installed Cooling | 1 × 92mm Rear Fan |
| Dust Filter | Bottom |
| Horizontal PCIe Slots | 4 |
| Vertical PCIe Slots | 3 |
| Front USB | 2 × USB 3.0 |
| Front USB Type-C | 1 × USB-C, 20Gbps |
| Audio | 1 × Combined Headset Jack |
| Front Controls | Power Button |
| Black Model EAN | 4710562742473 |
Three-Mode Hardware Compatibility
| Specification | M1 | M2 | I3 |
|---|---|---|---|
| Primary Purpose | Airflow-oriented | Cooling flexibility | Small-form-factor builds |
| Motherboard | Micro-ATX / Mini-ITX | Micro-ATX / Mini-ITX | Mini-ITX |
| CPU Cooler Height | 155mm | 155mm | 52mm |
| Horizontal GPU Length | 425mm | 410mm | 410mm |
| Vertical GPU Length | 410mm | 410mm | 410mm |
| Power Supply | ATX / SFX-L / SFX | ATX / SFX-L / SFX | SFX-L / SFX |
| PSU Mounting | Front / Motherboard Bracket | Front / Motherboard Bracket | Motherboard Bracket |
| Maximum 3.5-inch HDDs | 2 | 2 | Not supported |
| Maximum 2.5-inch SSDs | 4 | 4 | 3 |
| 360mm Side Radiator | With horizontal GPU | With horizontal GPU | With horizontal GPU |
| 360mm Top Radiator | Not supported | With vertical GPU | With vertical GPU |
| 360mm Bottom Radiator | With vertical GPU | Not supported | Not supported |
Radiator note: At applicable 360mm positions, radiator-size choices are 120, 140, 240, 280 and 360mm. Radiator support depends on mode and GPU orientation. The TEN ships with one 92mm rear fan and no pre-installed ARGB fans or glass side panel.
Cooling Support
| Mounting Position | Supported Fans |
|---|---|
| Top | 3 × 120mm or 2 × 140mm |
| Side | 3 × 120mm or 2 × 140mm |
| Bottom | 3 × 120mm or 2 × 140mm |
| Rear | 1 × 92mm |
| I3 Bottom | Depends on GPU dimensions |
