MONTECH-TEN-WHITE
MONTECH TEN White 22.7L Modular Micro-ATX Gaming Case, 3 Modes, Mesh Airflow, 425mm GPU (M1), 360mm Radiator Support, 92mm Rear Fan & 20Gbps USB-C
MONTECH TEN White 22.7L Modular Micro-ATX Gaming Case, 3 Modes, Mesh Airflow, 425mm GPU (M1), 360mm Radiator Support, 92mm Rear Fan & 20Gbps USB-C
69 $
TEN White — Expert Features
- Triple-Mode Modular Architecture : Choose M1, M2 or I3 to adjust motherboard, GPU, PSU, cooling and drive configurations.
- 22.7L Compact Main Frame : The compact core measures just 420 × 185 × 293mm; the complete enclosure occupies approximately 29.3L including protrusions.
- Premium Perforated Mesh : Extensive mesh paneling balances discreet hardware visibility with continuous ventilation.
- Chimney-Effect Airflow : A bottom-to-top ventilation concept promotes cool-air intake and rising heat exhaust in every configuration.
- Micro-ATX / Mini-ITX Compatibility : M1 and M2 support both board formats; I3 is designed exclusively for Mini-ITX.
- Up to 425mm GPU Clearance : M1 accommodates horizontal graphics cards up to 425mm; other published GPU configurations allow up to 410mm.
- Up to 360mm Radiator Support : Side, top or bottom radiator placement is available in specific mode and GPU-orientation combinations.
- Factory 92mm Rear Fan : One rear fan is included with every layout; additional system and radiator fans are optional.
- Flexible PSU Installation : M1/M2 support ATX, SFX-L and SFX units; I3 supports SFX-L and SFX units.
- Horizontal / Vertical GPU Options : Four horizontal and three vertical expansion slots allow multiple graphics-card layouts subject to accessory and clearance requirements.
- Flexible Drive Placement : M1/M2 offer up to two 3.5-inch HDDs or four 2.5-inch SSDs; I3 offers up to three 2.5-inch SSDs.
- 20Gbps USB Type-C : Front I/O includes high-speed USB Type-C, two USB 3.0 ports, a power button and a combined headset jack.
- Bottom Dust Filter : Dedicated lower filtration protects the primary low-level intake area.
- 10th Anniversary Accessories : Includes eight specialized Velcro straps, a protective bag with anniversary branding, a commemorative box sticker and a thank-you card.
TEN White — Expert Specs
General Chassis Specifications
| Specification | Details |
|---|---|
| Brand | MONTECH |
| Model | TEN |
| Color | White |
| Case Type | Compact Modular Micro-ATX / Mini-ITX Mesh Gaming Case |
| Configurations | M1 / M2 / I3 |
| Main Frame | 420 × 185 × 293mm (22.7L) |
| External Dimensions Excluding Protrusions | 442 × 196.5 × 326.05mm (28.3L) |
| External Dimensions Including Protrusions | 456 × 196.5 × 327.65mm (29.3L) |
| Carton Dimensions | 505 × 260 × 395mm |
| Construction | Perforated modular mesh enclosure |
| Included Fan | 1 × 92mm rear fan |
| Dust Filter | Bottom |
| Horizontal Expansion Slots | 4 |
| Vertical Expansion Slots | 3 |
| Power Button | 1 |
| Front USB-A | 2 × USB 3.0 |
| Front USB-C | 1 × USB Type-C (20Gbps) |
| Audio | 1 × combined headset jack |
| White Model EAN | 4710562746570 |
| Included Accessories | 8 × 10th Anniversary Velcro straps; thank-you card; anniversary exterior-box sticker; anniversary protective bag |
Configuration-Specific Compatibility
| Specification | M1 | M2 | I3 |
|---|---|---|---|
| Motherboards | Micro-ATX / Mini-ITX | Micro-ATX / Mini-ITX | Mini-ITX |
| Maximum CPU Cooler Height | 155mm | 155mm | 52mm |
| Maximum Horizontal GPU Length | 425mm | 410mm | 410mm |
| Maximum Vertical GPU Length | 410mm | 410mm | 410mm |
| Compatible PSU Formats | ATX / SFX-L / SFX | ATX / SFX-L / SFX | SFX-L / SFX |
| PSU Placement | Front / motherboard bracket | Front / motherboard bracket | Motherboard bracket |
| Maximum 3.5-inch HDDs | 2 | 2 | Not supported |
| Maximum 2.5-inch SSDs | 4 | 4 | 3 |
| Top Radiator | Not supported | 120 / 140 / 240 / 280 / 360mm with vertical GPU | 120 / 140 / 240 / 280 / 360mm with vertical GPU |
| Side Radiator | 120 / 140 / 240 / 280 / 360mm with horizontal GPU | 120 / 140 / 240 / 280 / 360mm with horizontal GPU | 120 / 140 / 240 / 280 / 360mm with horizontal GPU |
| Bottom Radiator | 120 / 140 / 240 / 280 / 360mm with vertical GPU | Not supported | Not supported |
Fan Mounting Support
| Position | Capacity | Notes |
|---|---|---|
| Top | 3 × 120mm or 2 × 140mm | All modes |
| Side | 3 × 120mm or 2 × 140mm | All modes |
| Bottom | 3 × 120mm or 2 × 140mm | I3 depends on GPU dimensions |
| Rear | 1 × 92mm | 1 × 92mm included |
Important: Radiator mounting is mode- and GPU-orientation-dependent. The advertised 22.7L describes the main frame, not the full exterior. The case has mesh panels rather than tempered-glass panels, and one 92mm rear fan is the only factory-installed fan.
